Displacement

Year

Model

Finish line

Parts catalogue

Parts diagram

ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA SUPER TENERE 1200 2017

ELECTRICAL 3

Item numbers

BATTERY (YTZ12-S)

23P821000000 23P821000000

222,47 €

Unit Price Incl. Tax

WIRE, MINUS LEAD

23P821160000 23P821160000

59,05 €

Unit Price Incl. Tax

BOLT, SOCKET

913120601200

913170601200

1,44 €

Unit Price Incl. Tax

STARTER RELAY ASSY (RC19-018)

4YR819400200 4YR819400200

125,68 €

Unit Price Incl. Tax

FUSE (12V 30A)

1AE821510000 1AE821510000

2,79 €

Unit Price Incl. Tax

BOLT, FLANGE

950220600800 950220600800

1,03 €

Unit Price Incl. Tax

RECTIFIER & REGULATOR ASSY

1D7819600100 1D7819600100

438,85 €

Unit Price Incl. Tax

PLATE, RECTIFIER FITTING

23P819750000 23P819750000

56,58 €

Unit Price Incl. Tax

BOLT, FLANGE

958020603000

958210603000

1,44 €

Unit Price Incl. Tax

RELAY ASSY (5VK-40)

5VK819504000

Not available

RELAY ASSY (1ST-00)

1ST819500000 1ST819500000

17,71 €

Unit Price Incl. Tax

HOLDER, RELAY

5JJ819520000 5JJ819520000

7,93 €

Unit Price Incl. Tax

RELAY ASSY

5JJ819501000

5JJ819501100

104,89 €

Unit Price Incl. Tax

SENSOR, LEAN ANGLE

5VU825760100

5VU825760200

170,92 €

Unit Price Incl. Tax

SCREW, TAPPING

977024002500 977024002500

0,98 €

Unit Price Incl. Tax

WASHER, PLATE

902010403000 902010403000

1,29 €

Unit Price Incl. Tax

NUT, ADJUSTING

4B4843340000 4B4843340000

4,56 €

Unit Price Incl. Tax

TERMINAL COMP.

23P8254B0000 23P8254B0000

99,62 €

Unit Price Incl. Tax

WIRE, SUB LEAD

23P825090000 23P825090000

54,53 €

Unit Price Incl. Tax

SCREW, HEXAGON (18V)

901530604400 901530604400

2,52 €

Unit Price Incl. Tax

WIRE, LEAD

23P825410000 23P825410000

9,52 €

Unit Price Incl. Tax

STAY, HORN

2BS8332P0000 2BS8332P0000

24,60 €

Unit Price Incl. Tax

BOLT, FLANGE

901050618100

958170601200

0,80 €

Unit Price Incl. Tax

HORN

BP8833710000 BP8833710000

79,54 €

Unit Price Incl. Tax

NUT, FLANGE(7NB)

957020650000

957010650000

2,23 €

Unit Price Incl. Tax

REFLECTOR, FRONT 1

4AG851110000 4AG851110000

15,40 €

Unit Price Incl. Tax

NUT, FLANGE(7NB)

957020650000

957010650000

2,23 €

Unit Price Incl. Tax

BRACKET REFLECTOR 1

23P851120100 23P851120100

26,53 €

Unit Price Incl. Tax

BRACKET REFLECTOR 2

23P851220100 23P851220100

26,53 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Choose your Yamaha 1200 XTZ SUPER TENERE 2017 model
