CYLINDER

CRANKSHAFT / PISTON FOR YAMAHA SUPER TENERE 1200 2017

VALVE

Item numbers

CRANKSHAFT ASSY

23P114000000 23P114000000

1 665,20 €

Unit Price Incl. Tax

CONNECTING ROD ASSY

23P116500000 23P116500000

201,52 €

Unit Price Incl. Tax

BOLT, CONNECTING ROD

23P116540000 23P116540000

6,77 €

Unit Price Incl. Tax

NUT (11H)

901790937900 901790937900

6,04 €

Unit Price Incl. Tax

PLANE BEARING, CONNECTING ROD

23P116560000 23P116560000

7,33 €

Unit Price Incl. Tax

PLANE BEARING, CONNECTING ROD

23P116561000 23P116561000

7,33 €

Unit Price Incl. Tax

PLANE BEARING, CONNECTING ROD

23P116562000 23P116562000

7,33 €

Unit Price Incl. Tax

PLANE BEARING, CONNECTING ROD

23P116563000 23P116563000

7,33 €

Unit Price Incl. Tax

PLANE BEARING, CRANKSHAFT 1

23P114160000 23P114160000

19,05 €

Unit Price Incl. Tax

PLANE BEARING, CRANKSHAFT 1

23P114161000 23P114161000

19,05 €

Unit Price Incl. Tax

PLANE BEARING, CRANKSHAFT 1

23P114162000 23P114162000

19,05 €

Unit Price Incl. Tax

PLANE BEARING, CRANKSHAFT 1

23P114163000 23P114163000

19,05 €

Unit Price Incl. Tax

PLANE BEARING, CRANKSHAFT 1

23P114164000 23P114164000

19,05 €

Unit Price Incl. Tax

KEY, WOODRUFF (26H)

902800502900 902800502900

11,48 €

Unit Price Incl. Tax

WASHER (838)

90201121H000

902011219100

10,05 €

Unit Price Incl. Tax

BOLT, WASHER BASED

901051200500 901051200500

40,45 €

Unit Price Incl. Tax

PISTON (STD)

2BS116310000 2BS116310000

194,17 €

Unit Price Incl. Tax

PISTON RING SET (STD)

2BS116030000

Not available

PIN, PISTON

4WM116330000 4WM116330000

53,05 €

Unit Price Incl. Tax

CIRCLIP

934502316700 934502316700

0,98 €

Unit Price Incl. Tax

BALANCER ASSY

23P115000100 23P115000100

1 021,36 €

Unit Price Incl. Tax

BALANCER ASSY, 2

23P115100100 23P115100100

782,10 €

Unit Price Incl. Tax

SHAFT, BALANCER 1

23P115830000 23P115830000

165,34 €

Unit Price Incl. Tax

PLANE BEARING, BALANCE WEIGHT

2S3114130000 2S3114130000

13,80 €

Unit Price Incl. Tax

PLANE BEARING, BALANCE WEIGHT

2S3114131000 2S3114131000

13,80 €

Unit Price Incl. Tax

PLANE BEARING, BALANCE WEIGHT

2S3114132000 2S3114132000

13,80 €

Unit Price Incl. Tax

PLANE BEARING, BALANCE WEIGHT

2S3114133000 2S3114133000

13,80 €

Unit Price Incl. Tax

ROTOR

23P816730000 23P816730000

48,14 €

Unit Price Incl. Tax

BOLT, FLANGE

901051015300 901051015300

6,72 €

Unit Price Incl. Tax

WASHER, PLATE

902011006500 902011006500

1,11 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
