SWITCH / LEVER

ELECTRICAL 1 FOR YAMAHA SUPER TENERE 1200 2017

ELECTRICAL 2

Item numbers

MAIN SW. IMMOBILIZER KIT

BP8W82500000

Not available

ENGINE CONTROL UNIT ASSY

BP88591A0000

BP88591A0100

1 022,31 €

Unit Price Incl. Tax

IMMOBILIZER. UNIT COMP.

2BS8255P0000 2BS8255P0000

800,05 €

Unit Price Incl. Tax

SCREW

5SL821130100 5SL821130100

2,68 €

Unit Price Incl. Tax

BLANK KEY

5SL825110800 5SL825110800

93,90 €

Unit Price Incl. Tax

IGNITION COIL ASSY

23P823100000 23P823100000

286,10 €

Unit Price Incl. Tax

WIRE, EARTH LEAD

2BS825190000 2BS825190000

9,14 €

Unit Price Incl. Tax

CLAMP

5Y9124910000 5Y9124910000

2,52 €

Unit Price Incl. Tax

BOLT, FLANGE

901050619800

901050619700

3,58 €

Unit Price Incl. Tax

NEUTRAL SWITCH ASSY

3GB825400100 3GB825400100

52,59 €

Unit Price Incl. Tax

GASKET (1KH, 1.0T)

904301014800 904301014800

3,05 €

Unit Price Incl. Tax

THERMOSENSOR ASSY

5YP857900000 5YP857900000

77,18 €

Unit Price Incl. Tax

WASHER, PLATE

902011279000 902011279000

4,70 €

Unit Price Incl. Tax

OIL LEVEL GAUGE ASSY

23P857200000 23P857200000

109,89 €

Unit Price Incl. Tax

O-RING

5VY8A8E00000 5VY8A8E00000

8,36 €

Unit Price Incl. Tax

BOLT, FLANGE

950220601600 950220601600

1,14 €

Unit Price Incl. Tax

CLAMP

904651004000 904651004000

6,42 €

Unit Price Incl. Tax

PICK-UP ASSY

23P816700000

23P816700100

O-RING 1

5VY8A8E10000 5VY8A8E10000

2,48 €

Unit Price Incl. Tax

PLATE

23P155890000 23P155890000

10,38 €

Unit Price Incl. Tax

BOLT, SOCKET

901100616100

Not available

WIRE HARNESS ASSY

2BS825900000 2BS825900000

2 423,53 €

Unit Price Incl. Tax

FUSE (7.5A-BL)

5JJ821510000 5JJ821510000

4,70 €

Unit Price Incl. Tax

FUSE

5JJ821512000 5JJ821512000

4,70 €

Unit Price Incl. Tax

FUSE (50A)

5JW821511000 5JW821511000

28,83 €

Unit Price Incl. Tax

FUSE (3A)

5JJ821515000

67F821513000

11,05 €

Unit Price Incl. Tax

FUSE

1MC821510000 1MC821510000

4,27 €

Unit Price Incl. Tax

BOLT, SOCKET

913120601200

913170601200

1,44 €

Unit Price Incl. Tax

CLAMP

904641600300 904641600300

2,00 €

Unit Price Incl. Tax

BAND, SWITCH CORD

437839360100 437839360100

4,99 €

Unit Price Incl. Tax

CLAMP

904651009800 904651009800

1,40 €

Unit Price Incl. Tax

CLAMP

904645500100 904645500100

2,08 €

Unit Price Incl. Tax

CLAMP

904643400200 904643400200

2,00 €

Unit Price Incl. Tax

CLAMP(4FM)

904641519500 904641519500

3,10 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307300

904641519500

3,10 €

Unit Price Incl. Tax

CLAMP

904642600100 904642600100

2,23 €

Unit Price Incl. Tax

CLAMP

904641600100 904641600100

2,68 €

Unit Price Incl. Tax

CLAMP

904641601900 904641601900

1,22 €

Unit Price Incl. Tax

GUIDE, CABLE

2BS233890000 2BS233890000

30,06 €

Unit Price Incl. Tax

BOLT

901090819500

901090819600

6,09 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
