EXHAUST

CRANKCASE FOR YAMAHA SUPER TENERE 1200 2017

COVER - ENGINE 1

Item numbers

CRANKCASE ASSY

23P151000900 23P151000900

5 591,68 €

Unit Price Incl. Tax

NOZZLE 1

4H7151380000

Not available

NOZZLE 1

2UJ151380000 2UJ151380000

8,11 €

Unit Price Incl. Tax

PIN, DOWEL

995301001400 995301001400

3,32 €

Unit Price Incl. Tax

PLUG

903381626200 903381626200

11,89 €

Unit Price Incl. Tax

O-RING(3LD)

932101279000 932101279000

1,73 €

Unit Price Incl. Tax

HOLDER

23P151280000 23P151280000

3,75 €

Unit Price Incl. Tax

BOLT, SOCKET

901100616100

Not available

PLUG

36Y151890000

Not available

O-RING(1L9)

932101632500 932101632500

4,08 €

Unit Price Incl. Tax

PLUG

4H7151890000 4H7151890000

22,84 €

Unit Price Incl. Tax

O-RING

93210207A000

932102080200

5,13 €

Unit Price Incl. Tax

BOLT, WITH WASHER

901191005100 901191005100

17,92 €

Unit Price Incl. Tax

BOLT, CRANKCASE JOURNAL

23P151560000 23P151560000

10,09 €

Unit Price Incl. Tax

O-RING (11M)

932100754000 932100754000

Not available

BOLT, FLANGE(JF2)

958120808000

958110808000

3,46 €

Unit Price Incl. Tax

BOLT, FLANGE

958120806000

958110806000

1,89 €

Unit Price Incl. Tax

BOLT

901090610000 901090610000

3,10 €

Unit Price Incl. Tax

BOLT, FLANGE

958120605000 958120605000

1,82 €

Unit Price Incl. Tax

BOLT, FLANGE

950220801600 950220801600

1,40 €

Unit Price Incl. Tax

WASHER, PLATE 3411117500

904300811900

902010808700

3,32 €

Unit Price Incl. Tax

GAUGE, LEVEL

2H7153610000 2H7153610000

29,54 €

Unit Price Incl. Tax

PIN, DOWEL(3VD)

995301011400 995301011400

2,12 €

Unit Price Incl. Tax

PLATE

3LD151910000 3LD151910000

12,10 €

Unit Price Incl. Tax

SCREW, COUNTERSUNK

901510602400

901510602300

1,03 €

Unit Price Incl. Tax

HOLDER

23P151180000 23P151180000

55,92 €

Unit Price Incl. Tax

PIN, DOWEL(3XW)

995300801600

995100801600

2,08 €

Unit Price Incl. Tax

BOLT, SOCKET

901100620800

913170603500

1,93 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
