STARTER CLUTCH

STARTER CLUTCH FOR YAMAHA XV535 1994

TRANSMISSION

NOT AVAILABLE

22U161110100

Not available

KEY, WOODRUFF (22U)

902800703600 902800703600

3,75 €

Unit Price Incl. Tax

WASHER, CLAW (11H)

902141602600 902141602600

10,50 €

Unit Price Incl. Tax

WASHER, LOCK (30X)

902151622200 902151622200

5,52 €

Unit Price Incl. Tax

NUT(24V)

901701631100

901701634300

9,48 €

Unit Price Incl. Tax

NOT AVAILABLE

22U161500100

Not available

PLATE, THRUST 1

22U161540000 22U161540000

11,48 €

Unit Price Incl. Tax

NOT AVAILABLE

22U163710000

Not available

PLATE, SEAT

4X7163840000 4X7163840000

14,60 €

Unit Price Incl. Tax

SPRING, CLUTCH BOSS

4X7163830100 4X7163830100

50,16 €

Unit Price Incl. Tax

PLATE, CLUTCH 1

4X7163240000

Not available

RING, CLUTCH BOSS

4X7163850000 4X7163850000

6,77 €

Unit Price Incl. Tax

PLATE, FRICTION

22U163210000 22U163210000

17,43 €

Unit Price Incl. Tax

PLATE, CLUTCH 2

4X7163250000

Not available

PLATE, PRESSURE 1

22U163510000 22U163510000

118,71 €

Unit Price Incl. Tax

SPRING, COMPRESSION (22U)

905012373800 905012373800

10,21 €

Unit Price Incl. Tax

SCREW, WITH WASHER (1W4)

901590601600 901590601600

4,56 €

Unit Price Incl. Tax

PLATE, PUSH

30X163580000

1W1163580100

13,94 €

Unit Price Incl. Tax

NOT AVAILABLE

5Y1163560000

Not available

O-RING (5Y1)

932100952500 932100952500

3,79 €

Unit Price Incl. Tax

YBS66-6 WASHER, PLAIN 5PK

929010620000

929900620000

1,14 €

Unit Price Incl. Tax

NUT(661)

953030660000

953800660000

3,10 €

Unit Price Incl. Tax

WASHER, LOCK(47X)

902152224400 902152224400

5,26 €

Unit Price Incl. Tax

NUT (26H)

901702031000

901702032300

13,62 €

Unit Price Incl. Tax

BRG, CYL-CAL ROLLER 12G KY

933152181300 933152181300

17,76 €

Unit Price Incl. Tax

OIL SEAL (22U)

931021827800 931021827800

7,58 €

Unit Price Incl. Tax

PUSH LEVER ASSY

22U163800000 22U163800000

101,07 €

Unit Price Incl. Tax

SPRING, TORSION (22U)

905081657700 905081657700

4,61 €

Unit Price Incl. Tax

WASHER PLATE 168217580000

902011826200 902011826200

2,98 €

Unit Price Incl. Tax

WASHER, PLATE 3411117500

902010808700 902010808700

3,32 €

Unit Price Incl. Tax

SCREW 425163430000

901490806700 901490806700

5,26 €

Unit Price Incl. Tax

ROD, PUSH 2

22U163570000 22U163570000

71,19 €

Unit Price Incl. Tax

BALL (1M1)

935153202900 935153202900

2,84 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha XV535 of 1994. Let us know if you have any questions.
