CARBURETOR

EXHAUST FOR YAMAHA XV535 1994

CRANKCASE

NOT AVAILABLE

2YL147031000

Not available

BOLT (11T)

901010657600 901010657600

2,37 €

Unit Price Incl. Tax

WASHER(6TA) 10PK

929060660000

929070660000

1,14 €

Unit Price Incl. Tax

SCREW PAN HEAD 5PK

985800602000 985800602000

2,90 €

Unit Price Incl. Tax

WASHER, PLATE (4H7)

929010660000

90201061A500

2,19 €

Unit Price Incl. Tax

NUT (22U) 5PK

901790841000 901790841000

4,27 €

Unit Price Incl. Tax

GASKET, EXHAUST PIPE

4BE146130000 4BE146130000

16,37 €

Unit Price Incl. Tax

BOLT, HEXAGON

970260803000

970160803000

3,10 €

Unit Price Incl. Tax

NOT AVAILABLE

929060870000

Not available

WASHER(6TA)

929060860000

929070860000

1,14 €

Unit Price Incl. Tax

GASKET, EXHAUST PIPE

4BR146130000 4BR146130000

16,37 €

Unit Price Incl. Tax

NOT AVAILABLE

2GV146250000

Not available

BOLT, SOCKET HEAD

913110602500

913140602500

1,93 €

Unit Price Incl. Tax

NUT, SELF-LOCKING(3BN)

901850809700

901850814600

3,67 €

Unit Price Incl. Tax

NUT, HEXAGON SMALL

953160870000

953170870000

2,00 €

Unit Price Incl. Tax

PLATE, AIR CLEANER

2GV146630000 2GV146630000

60,86 €

Unit Price Incl. Tax

BOLT, FLANGE

958010601600

958110601600

1,44 €

Unit Price Incl. Tax

COVER 1

2GV146030000 2GV146030000

137,51 €

Unit Price Incl. Tax

SCREW, TAPPING(3BM)

977014001200

977044001200

1,14 €

Unit Price Incl. Tax

SCREW, TAPPING(2GV)

901630400300 901630400300

1,93 €

Unit Price Incl. Tax

NUT, SPRING (26H)

901830402700 901830402700

2,19 €

Unit Price Incl. Tax

NOT AVAILABLE

2GV144840000

Not available

NOT AVAILABLE

2GV2138L0000

Not available

BLT, HEX, 1/4-20X5/8 10PK

958160801600

958170801600

2,12 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the EXHAUST of your Yamaha XV535 of 1994. Let us know if you have any questions.
