Parts diagram

HANDLEBAR & CABLES

FRONT MASTER CYLINDER FOR YAMAHA XP500R 2003

STAND / FOOTREST

FRONT MASTER CYLINDER Yamaha SCOOTER 500 2003 TMAX XP500R
1
MASTER CYLINDER SUB ASSY

5GJ258700000  

5RU258702000
 5GJ258700000

Unit Price Incl. Tax

2
CYLINDER KIT, MASTER

5GJW00410000  

5VUW00410000
 5GJW00410000

Unit Price Incl. Tax

3
DIAPHRAGM, RESERVOIR

3YX258540000   3YX258540000

3YX258540000

Unit Price Incl. Tax

4
CAP, RESERVOIR

4TX258520200  

4TX258520100
 4TX258520200

Unit Price Incl. Tax

5
SCREW, FLAT 5PK

987060401200  

987070401200
 987060401200

Unit Price Incl. Tax

6
PLATE, RESERVOIR

3YX258960000   3YX258960000

3YX258960000

Unit Price Incl. Tax

7
BRACKET, MASTER CYLINDER

3RW258670000  

56A258670000
 3RW258670000

Unit Price Incl. Tax

8
BOLT, SOCKET

913170602500   913170602500

913170602500

Unit Price Incl. Tax

9
NOT AVAILABLE

5GJ258720000  

5GJ258720000
Not available
10
BOLT, UNION

904011017200   904011017200

904011017200

Unit Price Incl. Tax

11
WASHER, PLATE

902011011800  

90201108J900
 902011011800

Unit Price Incl. Tax

12
NOT AVAILABLE

5GJ258751000  

5GJ258751000
Not available
13
BOLT, FLANGE

958070601600  

958170601600
 958070601600

Unit Price Incl. Tax

14
HOLDER, BRAKE HOSE 1

5GJ258750000   5GJ258750000

5GJ258750000

Unit Price Incl. Tax

15
BOLT, FLANGE

958070601000  

958170601000
 958070601000

Unit Price Incl. Tax

16
NOT AVAILABLE

5GJ258760000  

5GJ258760000
Not available
17
BOLT, FLANGE

958070602000  

958170602000
 958070602000

Unit Price Incl. Tax

18
NOT AVAILABLE

5GJ258701000  

5GJ258701000
Not available
19
CYLINDER KIT, MASTER

5GJW00411000  

1B7W00410000
 5GJW00411000

Unit Price Incl. Tax

20
DIAPHRAGM, RESERVOIR

3YX258540000   3YX258540000

3YX258540000

Unit Price Incl. Tax

21
CAP, RESERVOIR

4TX258520200  

4TX258520100
 4TX258520200

Unit Price Incl. Tax

22
SCREW, FLAT 5PK

987060401200  

987070401200
 987060401200

Unit Price Incl. Tax

23
PLATE, RESERVOIR

3YX258960000   3YX258960000

3YX258960000

Unit Price Incl. Tax

24
BRACKET, MASTER CYLINDER

3RW258670000  

56A258670000
 3RW258670000

Unit Price Incl. Tax

25
BOLT, SOCKET

913170602500   913170602500

913170602500

Unit Price Incl. Tax

26
NOT AVAILABLE

5GJ2584A0000  

5GJ2584A0000
Not available
27
BOLT, UNION

904011017200   904011017200

904011017200

Unit Price Incl. Tax

28
WASHER, PLATE

902011011800  

90201108J900
 902011011800

Unit Price Incl. Tax

29
CLAMP(3LD)

904640912900   904640912900

904640912900

Unit Price Incl. Tax

30
HOLDER, BRAKE HOSE

5GJ258861000   5GJ258861000

5GJ258861000

Unit Price Incl. Tax

31
BOLT, FLANGE

958070601000  

958170601000
 958070601000

Unit Price Incl. Tax

32
CLAMP(56R)

904646006700   904646006700

904646006700

Unit Price Incl. Tax

33
NOT AVAILABLE

5GJ224650000  

5GJ224650000
Not available
34
BOLT, FLANGE

958070801200  

958170801200
 958070801200

Unit Price Incl. Tax

35
CLAMP(1NL)

904651431000   904651431000

904651431000

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
