EXHAUST

CRANKCASE FOR YAMAHA XP500R 2003

COVER - ENGINE 1

CRANKCASE Yamaha SCOOTER 500 2003 TMAX XP500R
1
NOT AVAILABLE

5GJ151000000  

5GJ151000000
Not available
2
PIN, DOWEL(3VD)

995301011400   995301011400

995301011400

Unit Price Incl. Tax

3
BOLT, SMALL FLANGE

950270603500   950270603500

950270603500

Unit Price Incl. Tax

4
BOLT, WASHER BASED(4KG)

950270605000  

901050679800
 950270605000

Unit Price Incl. Tax

5
NOT AVAILABLE

950270811000  

950270811000
Not available
6
BOLT 1

5GJ154810000  

15B154810000
 5GJ154810000

Unit Price Incl. Tax

7
GASKET

214111980100   214111980100

214111980100

Unit Price Incl. Tax

8
O-RING (2H7) 5PK

932104836400   932104836400

932104836400

Unit Price Incl. Tax

9
PLUG

4H7151890000   4H7151890000

4H7151890000

Unit Price Incl. Tax

10
O-RING (25G) 5PK

932102238200  

932102057300
 932102238200

Unit Price Incl. Tax

11
BOLT, SOCKET

901100800400  

913140801200
 901100800400

Unit Price Incl. Tax

12
WASHER, PLATE 3411117500

904300811900  

902010808700
 904300811900

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
