SWITCH / LEVER

ELECTRICAL 1 FOR YAMAHA AG 200 FE 2013

C.D.I. UNIT ASSY

3GX855401000

3GX855401100

334,08 €

Unit Price Incl. Tax

BAND

3GX855460000 3GX855460000

53,27 €

Unit Price Incl. Tax

IGNITION COIL ASSY

4JG823100000

4JG823100100

83,48 €

Unit Price Incl. Tax

BOLT, WASHER BASED(JA9)

950270601600

901050669600

2,90 €

Unit Price Incl. Tax

PLUG CAP ASSY

3NS823700000 3NS823700000

60,02 €

Unit Price Incl. Tax

NEUTRAL SWITCH ASSY

4KM825400000

4GY825401000

30,10 €

Unit Price Incl. Tax

GASKET (1KH, 1.0T)

904301014800 904301014800

3,05 €

Unit Price Incl. Tax

BATTERY (YTZ7S)

1S4821001000

Not available

FUSE H0LDER ASSY

55K821500100

Not available

FUSE

116821510000

1A0821510000

8,49 €

Unit Price Incl. Tax

RECTIFIER & REGULATOR ASSY

3TJ819600200 3TJ819600200

161,14 €

Unit Price Incl. Tax

STRIP, WEATHER 2

8U9771620000 8U9771620000

2,08 €

Unit Price Incl. Tax

SCREW, PAN HEAD (76T)

985070602500

985170602500

1,11 €

Unit Price Incl. Tax

STOP SWITCH ASSY

2F1825300200 2F1825300200

73,58 €

Unit Price Incl. Tax

WIRE HARNESS ASSY

53C825900000 53C825900000

343,35 €

Unit Price Incl. Tax

MAIN SWITCH ASSY

53C825100000

Not available

CAP, KEY

24W825790000 24W825790000

39,21 €

Unit Price Incl. Tax

SCREW, PAN

985070501200

985170501200

1,89 €

Unit Price Incl. Tax

WASHER(1RW)

929070560000 929070560000

1,14 €

Unit Price Incl. Tax

BAND 5PK

1UA825910000 1UA825910000

2,60 €

Unit Price Incl. Tax

CLAMP

904640726200 904640726200

4,27 €

Unit Price Incl. Tax

CLAMP (6G5)

9046407M0500 9046407M0500

3,58 €

Unit Price Incl. Tax

RELAY ASSY

1RL819509200

12R819500100

110,69 €

Unit Price Incl. Tax

STARTER RELAY ASSY (RC19-004)

4FU819400200 4FU819400200

100,32 €

Unit Price Incl. Tax

FUSE (20A)

2GH821510000

2GV821510000

4,27 €

Unit Price Incl. Tax

BOLT, SMALL FLANGE

950270600800 950270600800

0,98 €

Unit Price Incl. Tax

WIRE, PLUS LEAD

3GX821151000 3GX821151000

32,99 €

Unit Price Incl. Tax

WIRE, MINUS LEAD

3GX821160000 3GX821160000

21,03 €

Unit Price Incl. Tax

TERMINAL ASSY

59V819200000 59V819200000

189,22 €

Unit Price Incl. Tax

COVER

59V819420000 59V819420000

10,91 €

Unit Price Incl. Tax

NUT (8J2)

901790527100 901790527100

11,00 €

Unit Price Incl. Tax

HOSE (L1050)

90445070K700

904450717600

13,54 €

Unit Price Incl. Tax

SCREW, PAN HEAD (E22)

978800502000

978850502000

2,23 €

Unit Price Incl. Tax

WASHER, PLAIN (646)

929900560000 929900560000

1,14 €

Unit Price Incl. Tax

WIRE, SUB LEAD

3GX825090000 3GX825090000

4,08 €

Unit Price Incl. Tax

HORN

3TY833711100 3TY833711100

59,05 €

Unit Price Incl. Tax

BOLT, FLANGE

958070601200

958170601200

0,80 €

Unit Price Incl. Tax

FLASHER RELAY ASSY

4GY833500000

4GY833500100

115,56 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 1 of your Yamaha AG 200 FE of 2013. Let us know if you have any questions.
