CYLINDER

CRANKSHAFT / PISTON FOR YAMAHA AG 200 FE 2013

VALVE

(1) 999990158600

CRANKSHAFT ASSY

(2) 5H0-11401-09

CRANK SUB ASSY 1

(3) 5H0-11422-00

CRANK 2

(4) 5H0-11681-00

PIN, CRANK 1

(5) 93310-530J3

BEARING, CYLINDRICAL (5H0)

(6) 15A-11651-00

ROD, CONNECTING

(7) 933063061500

BRG,R-B 6306 72MM 351G KY

(8) 36X-11631-00-A0

PISTON (STD)

(8) 36X-11636-00

PISTON (2ND 0/S 0.50MM)

(8) 36X-11638-00

PISTON (4TH 0/S 1.00MM)

(9) 15A-11603-00

PISTON RING SET (STD)

(9) 15A-11605-00

PISTON RING SET (0.50MM O/S)

(9) 15A-11607-00

PISTON RING SET (1.00MM O/S)

(10) 58L116330000

PIN, PISTON

(11) 934501704400

CIRCLIP (1L9)

(12) 90201-201E4

WASHER, PLATE (5H0)

(13) 5H0-11496-00

BOSS, BUFFER

(14) 90501-21133

SPRING COMPRESSION341114880000

(15) 93605-10090

PIN, DOWEL

(16) 5H0-11536-00

GEAR, DRIVE

(17) 90214-20023

WASHER, CLAW (5H0)

(18) 90240-07083

PIN, CLEVIS (5H0)

(19) 90501-07629

SPRING, COMPRESSION (5H0)

(20) 93602-13177

PIN, DOWEL (5H0)

(21) 5H0-11531-00

GEAR, BALANCE WT

(22) 15A-11454-00

WEIGHT 1

(23) 933063044300

BEARING

(24) 933063044300

BEARING

(25) 902820506500

KEY, STRAIGHT(34K)

(26) 90215-14205

WASHER, LOCK (15Y)

(27) 90170-14284

NUT (5H0)

(28) 902800500100

KEY, WOODRUFF

(29) 90201102J500

WASHER, PLATE(52H)

(30) 90101-10188

BOLT (341)

	Part number	Description	Qty
# 1	5H0-11400-00 5H01140000	CRANKSHAFT ASSY	Not available	0,00 €
# 2	5H0-11401-09 5H01140109 5H01140109	CRANK SUB ASSY 1	612,87 €
# 3	5H0-11422-00 5H01142200 5H01142200	CRANK 2	343,98 €
# 4	5H0-11681-00 5H01168100 5H01168100	PIN, CRANK 1	81,93 €
# 5	93310-530J3 93310530J3 93310530J3	BEARING, CYLINDRICAL (5H0)	68,95 €
# 6	15A-11651-00 15A1165100 15A1165100	ROD, CONNECTING	119,38 €
# 7	93306-30611 933063061500 9330630611	BRG, R-B 6306 72MM 351G KY	48,74 €
# 8	36X-11631-00-A0 36X1163100A0 36X1163100A0	PISTON (STD)	159,35 €
# 8	36X-11636-00 36X1163600 36X1163600	PISTON (2ND 0/S 0.50MM)	123,68 €
# 8	36X-11638-00 36X1163800 36X1163800	PISTON (4TH 0/S 1.00MM)	123,68 €
# 9	15A-11603-00 15A1160300 15A1160300	PISTON RING SET (STD)	58,34 €
# 9	15A-11605-00 15A1160500 15A1160500	PISTON RING SET (0.50MM O/S)	58,34 €
# 9	15A-11607-00 15A1160700 15A1160700	PISTON RING SET (1.00MM O/S)	58,34 €
# 10	15A-11633-00 58L116330000 15A1163300	PIN, PISTON	48,78 €
# 11	934501704400 934501704400 934501704400	CIRCLIP (1L9)	2,57 €
# 12	90201-201E4 90201201E4 90201201E4	WASHER, PLATE (5H0)	19,79 €
# 13	5H0-11496-00 5H01149600 5H01149600	BOSS, BUFFER	119,43 €
# 14	90501-21133 9050121133 9050121133	SPRING COMPRESSION341114880000	5,20 €
# 15	93605-10090 9360510090 9360510090	PIN, DOWEL	3,37 €
# 16	5H0-11536-00 5H01153600 5H01153600	GEAR, DRIVE	86,20 €
# 17	90214-20023 9021420023 9021420023	WASHER, CLAW (5H0)	9,96 €
# 18	90240-07083 9024007083 9024007083	PIN, CLEVIS (5H0)	16,37 €
# 19	90501-07629 9050107629 9050107629	SPRING, COMPRESSION (5H0)	2,52 €
# 20	93602-13177 9360213177 9360213177	PIN, DOWEL (5H0)	2,88 €
# 21	5H0-11531-00 5H01153100 5H01153100	GEAR, BALANCE WT	125,29 €
# 22	15A-11454-00 15A1145400 15A1145400	WEIGHT 1	133,42 €
# 23	93306-30427 933063044300 9330630427	BEARING	47,00 €
# 24	93306-30427 933063044300 9330630427	BEARING	47,00 €
# 25	90282-05013 902820506500 9028205013	KEY, STRAIGHT(34K)	3,43 €
# 26	90215-14205 9021514205 9021514205	WASHER, LOCK (15Y)	2,19 €
# 27	90170-14284 9017014284 9017014284	NUT (5H0)	1,37 €
# 28	90280-05048 902800500100 9028005048	KEY, WOODRUFF	11,14 €
# 29	90201-10508 90201102J500 9020110508	WASHER, PLATE(52H)	11,80 €
# 30	90101-10188 9010110188 9010110188	BOLT (341)	5,12 €

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CRANKSHAFT / PISTON of your Yamaha AG 200 FE of 2013. Let us know if you have any questions.
