ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA EC-03 2011

Item numbers

MAIN SWITCH STEERING LOCK

1CB825010000 1CB825010000

250,22 €

Unit Price Incl. Tax

BLANK KEY

4BH825110900 4BH825110900

30,95 €

Unit Price Incl. Tax

SCREW

901490800200 901490800200

2,90 €

Unit Price Incl. Tax

WIRE HARNESS ASSY

1CB825900000 1CB825900000

453,96 €

Unit Price Incl. Tax

FUSE (5A-LP BL)

1CB821510000 1CB821510000

4,27 €

Unit Price Incl. Tax

FUSE (7.5A-LP BL)

1CB821511000 1CB821511000

4,27 €

Unit Price Incl. Tax

FUSE (10A)

5JJ821513000

67F821514000

11,05 €

Unit Price Incl. Tax

FUSE (3A)

5JJ821515000

67F821513000

11,05 €

Unit Price Incl. Tax

GUIDE, WIRE HARNESS

5UY213971100 5UY213971100

26,19 €

Unit Price Incl. Tax

CLAMP, CABLE

5UY213371100 5UY213371100

24,77 €

Unit Price Incl. Tax

BOLT, BUTTON HEAD

920170601000 920170601000

2,12 €

Unit Price Incl. Tax

CLAMP

904641600100 904641600100

2,68 €

Unit Price Incl. Tax

HORN

1CB833710000 1CB833710000

42,45 €

Unit Price Incl. Tax

BOLT, FLANGE (29L)

958020601000

958010601000

1,14 €

Unit Price Incl. Tax

GUIDE, WIRE

5UY213390100 5UY213390100

10,05 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 2 of your Yamaha EC-03 of 2011. Let us know if you have any questions.
