ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA FZ8N 2013

SWITCH, SIDE STAND

23P825666000 23P825666000

116,27 €

Unit Price Incl. Tax

BOLT, BUTTON HEAD

920120503000 920120503000

1,29 €

Unit Price Incl. Tax

NUT, U FLANGE

956020520000

956010520000

2,90 €

Unit Price Incl. Tax

STOP SWITCH ASSY

39P825300000

Not available

MAIN SW. IMMOBILIZER KIT

39PW82502000 39PW82502000

1 762,59 €

Unit Price Incl. Tax

ENGINE CONTROL UNIT ASSY

39P8591A4000

Not available

IMMOBILIZER. UNIT COMP.

39P8255P0000 39P8255P0000

575,95 €

Unit Price Incl. Tax

SCREW

5SL821130100 5SL821130100

2,68 €

Unit Price Incl. Tax

BLANK KEY

5SL825110800 5SL825110800

93,90 €

Unit Price Incl. Tax

BATTERY (YTZ10S)

5VY821000000 5VY821000000

214,12 €

Unit Price Incl. Tax

SPACER

39P8246K0000 39P8246K0000

17,08 €

Unit Price Incl. Tax

BAND, BATTERY

2D1821310000 2D1821310000

10,91 €

Unit Price Incl. Tax

HOOK

5YU2162A0000 5YU2162A0000

8,14 €

Unit Price Incl. Tax

STARTER RELAY ASSY (RC19-054)

2C0819400000 2C0819400000

121,52 €

Unit Price Incl. Tax

FUSE (12V 15A)

36Y821510000 36Y821510000

4,78 €

Unit Price Incl. Tax

COVER, LEAD WIRE

5SL821191000 5SL821191000

6,16 €

Unit Price Incl. Tax

DAMPER

39P821760000 39P821760000

5,47 €

Unit Price Incl. Tax

DAMPER

39P821570000 39P821570000

1,44 €

Unit Price Incl. Tax

BOLT, FLANGE

950220600800 950220600800

1,03 €

Unit Price Incl. Tax

WIRE HARNESS ASSY

39P825903000 39P825903000

1 303,46 €

Unit Price Incl. Tax

FUSE (15A)

5JJ821511000

67F821515000

2,42 €

Unit Price Incl. Tax

FUSE (10A)

5JJ821513000

67F821514000

11,05 €

Unit Price Incl. Tax

FUSE (50A)

5JW821511000 5JW821511000

28,83 €

Unit Price Incl. Tax

RECTIFIER & REGULATOR ASSY

1D7819600100 1D7819600100

438,85 €

Unit Price Incl. Tax

BOLT, FLANGE

958220602500

958170602500

1,11 €

Unit Price Incl. Tax

RELAY ASSY (5VK-40)

5VK819504000

Not available

RELAY ASSY (5JJ-20)

5JJ819502000 5JJ819502000

104,89 €

Unit Price Incl. Tax

HOLDER, RELAY

5JJ819520000 5JJ819520000

7,93 €

Unit Price Incl. Tax

RELAY ASSY (5JJ-20)

5JJ819502000 5JJ819502000

104,89 €

Unit Price Incl. Tax

HOLDER, RELAY

5JJ819520000 5JJ819520000

7,93 €

Unit Price Incl. Tax

FLASHER RELAY ASSY

4GY833500000

4GY833500100

115,56 €

Unit Price Incl. Tax

SENSOR, LEAN ANGLE

5PS825760100 5PS825760100

123,62 €

Unit Price Incl. Tax

BOLT

913120402500 913120402500

1,11 €

Unit Price Incl. Tax

WASHER, PLATE

902010403000 902010403000

1,29 €

Unit Price Incl. Tax

NUT, SPRING(47R)

901830403900 901830403900

10,09 €

Unit Price Incl. Tax

BOLT

901090819500

901090819600

6,09 €

Unit Price Incl. Tax

CLAMP(2TV) 5PK

904641203600

904641011200

5,52 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307300

904641519500

3,10 €

Unit Price Incl. Tax

CLAMP(4FM)

904641519500 904641519500

3,10 €

Unit Price Incl. Tax

BOLT, SOCKET

913800601000 913800601000

2,12 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307700

904641307300

3,10 €

Unit Price Incl. Tax

WIRE, MINUS LEAD

2D1821160000 2D1821160000

32,07 €

Unit Price Incl. Tax

HORN

39P833710000 39P833710000

72,11 €

Unit Price Incl. Tax

CLAMP

904651009800 904651009800

1,40 €

Unit Price Incl. Tax

CLAMP

904645900100 904645900100

18,39 €

Unit Price Incl. Tax

BOLT, BUTTON HEAD

920120601400 920120601400

1,40 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 2 of your Yamaha FZ8N of 2013. Let us know if you have any questions.
