CRANKCASE FOR YAMAHA ACTIVE 1992

STARTER MOTOR

(1) 2XX-15110-00-00

CRANKCASE ASSY 1

(2) 164-22216-00-00

BUSHING, REAR CUSHION

(3) 93306-00201-00

BRG,R-B 6002RS 32MM 30G KY

(5) 93306-00201-00

BRG,R-B 6002RS 32MM 30G KY

(6) 3YJ-15371-00-00

BREATHER

(7) 2GM-15120-01-00

CRANKCASE ASSY 2

(8) 995301201600

PIN, DOWEL

(9) 985800601000

SCREW PAN HEAD

(10) 985800604000

SCREW PAN HEAD

(11) 985800654500

SCREW PAN HEAD

(12) 1GJ-15317-00-00

SPACER, ENGINE MOUNT

(13) 990091540000

CIRCLIP(1AR)

(14) 1HV-15421-01-00

COVER, CRANKCASE 2

(15) 3WX154510000

GASKET, CRANKCASE COVER 1

(16) 99530-10014-00

PIN, DOWEL

(17) 913170603500

BOLT,SOCKET

(18) 913170602000

BOLT,SOCKET

(19) 2GM-W1541-01-00

CRANKCASE COVER ASSY 1

(20) 93300-63813-00

BEARING

(21) 99530-10014-00

PIN, DOWEL

(22) 985170602500

SCREW, PAN HEAD (76T)

(23) 985070603500

SCREW, PAN

(24) 985070607000

SCREW, PAN HEAD

(25) 92990-06600-00

WASHER, PLAIN (646)

(26) 4J2153631000

PLUG, OIL

(27) 932101457900

O-RING (26H)

(28) 9010508X1500

BLT,HEX,1/4-20X5/8

(29) 90201-08087-00

WASHER, PLATE 3411117500

(30) 1HV-15128-00-00

HOLDER

(31) 985170601200

SCREW, PAN

(32) 3WX154620000

GASKET, CRANKCASE COVER 3

(33) 24G-15416-00-00

COVER, OIL PUMP

(34) 90159-06075-00

SCREW, WITH WASHER (33A)

(35) 90480-01300-00

GROMMET (5G3)

(36) 90465-20315-00

CLAMP(2GM)

(37) 2XX154710100

DUCT AIR 1

(38) 2GM-15191-00-00

PLATE

(39) 2GM-15407-00-00

ELEMENT 1

(40) 2GM-15408-00-00

ELEMENT 2

(41) 2GM-15472-00-00

SEAL, AIR DUCT

(42) 90176-06065-00

NUT, CROWN(2GM)

(43) 970800604000

BOLT(J52)

(44) 32N-14437-00-00

DUCT

(45) 2XX-15431-00-00

COVER, CRANKCASE 3

(46) 2XX-15316-00-00

DAMPER, ENGINE MOUNT 1

(47) 2JA-15335-00-00

DAMPER 3

(48) 904801249700

GROMMET(3AA)

(49) 90387-060L4-00

COLLERETTE

(50) 90480-12237-00

GROMMET (2T4)

(51) 90159-06151-00

SCREW, WITH WASHER(2JA)

(52) 1GJ-1541F-00-00

STAY, COVER 3

(53) 54V-15484-00-00

CLAMP 2

(54) 90465-10296-00

CLAMP(1GJ)

	Part number	Description	Qty
# 1	2XX-15110-00-00 2XX151100000 2XX151100000	CRANKCASE ASSY 1	Not available	0,00 €
# 2	164-22216-00-00 164222160000 164222160000	BUSHING, REAR CUSHION	8,38 €
# 3	93306-00201-00 933060020100 933060020100	BRG, R-B 6002RS 32MM 30G KY	50,34 €
# 5	93306-00201-00 933060020100 933060020100	BRG, R-B 6002RS 32MM 30G KY	50,34 €
# 6	3YJ-15371-00-00 3YJ153710000 3YJ153710000	BREATHER	4,71 €
# 7	2GM-15120-01-00 2GM151200100 2GM151200100	CRANKCASE ASSY 2	Not available	0,00 €
# 8	99510-12016-00 995301201600 995101201600	PIN, DOWEL	3,43 €
# 9	98501-06010-00 985800601000 985010601000	SCREW PAN HEAD	3,06 €
# 10	98501-06040-00 985800604000 985010604000	SCREW PAN HEAD	3,37 €
# 11	98503-06045-00 985800654500 985030604500	SCREW PAN HEAD	4,39 €
# 12	1GJ-15317-00-00 1GJ153170000 1GJ153170000	SPACER, ENGINE MOUNT	Not available	0,00 €
# 13	93440-15012-00 990091540000 934401501200	CIRCLIP(1AR)	3,06 €
# 14	1HV-15421-01-00 1HV154210100 1HV154210100	COVER, CRANKCASE 2	Not available	0,00 €
# 15	27V-15451-03-00 27V154510300	GASKET, CRANKCASE COVER 1	Not available	0,00 €
# 16	99530-10014-00 995301001400 995301001400	PIN, DOWEL	3,06 €
# 17	91316-06035-00 913170603500 913160603500	BOLT, SOCKET	1,37 €
# 18	91316-06020-00 913170602000 913160602000	BOLT, SOCKET	0,36 €
# 19	2GM-W1541-01-00 2GMW15410100 2GMW15410100	CRANKCASE COVER ASSY 1	Not available	0,00 €
# 20	93300-63813-00 933006381300 933006381300	BEARING	39,36 €
# 21	99530-10014-00 995301001400 995301001400	PIN, DOWEL	3,06 €
# 22	98506-06025-00 985170602500 985060602500	SCREW, PAN HEAD (76T)	0,50 €
# 23	98506-06035-00 985070603500 985060603500	SCREW, PAN	0,60 €
# 24	98506-06070-00 985070607000 985060607000	SCREW, PAN HEAD	2,05 €
# 25	92990-06600-00 929900660000 929900660000	WASHER, PLAIN (646)	0,60 €
# 26	4J2-15363-00-00 4J2153631000 4J2153630000	PLUG, OIL	5,12 €
# 27	93210-14104-00 932101457900 932101410400	O-RING (26H)	1,56 €
# 28	95811-08016-00 9010508X1500 958110801600	BLT, HEX, 1/4-20X5/8	1,61 €
# 29	90201-08087-00 902010808700 902010808700	WASHER, PLATE 3411117500	3,06 €
# 30	1HV-15128-00-00 1HV151280000 1HV151280000	HOLDER	4,39 €
# 31	98501-06012-00 985010601200	SCREW, PAN	Not available	0,00 €
# 32	14T-15462-00-00 14T154620000	GASKET, CRANKCASE COVER 3	Not available	0,00 €
# 33	24G-15416-00-00 24G154160000 24G154160000	COVER, OIL PUMP	Not available	0,00 €
# 34	90159-06075-00 901590607500 901590607500	SCREW, WITH WASHER (33A)	Not available	0,00 €
# 35	90480-01300-00 904800130000 904800130000	GROMMET (5G3)	Not available	0,00 €
# 36	90465-20315-00 904652031500 904652031500	CLAMP(2GM)	Not available	0,00 €
# 37	2GM-15471-01-00 2GM154710100	DUCT AIR 1	Not available	0,00 €
# 38	2GM-15191-00-00 2GM151910000 2GM151910000	PLATE	Not available	0,00 €
# 39	2GM-15407-00-00 2GM154070000 2GM154070000	ELEMENT 1	Not available	0,00 €
# 40	2GM-15408-00-00 2GM154080000 2GM154080000	ELEMENT 2	Not available	0,00 €
# 41	2GM-15472-00-00 2GM154720000 2GM154720000	SEAL, AIR DUCT	Not available	0,00 €
# 42	90176-06065-00 901760606500 901760606500	NUT, CROWN(2GM)	1,61 €
# 43	97001-06040-00 970800604000 970010604000	BOLT(J52)	4,90 €
# 44	32N-14437-00-00 32N144370000 32N144370000	DUCT	Not available	0,00 €
# 45	2XX-15431-00-00 2XX154310000 2XX154310000	COVER, CRANKCASE 3	Not available	0,00 €
# 46	2XX-15316-00-00 2XX153160000 2XX153160000	DAMPER, ENGINE MOUNT 1	Not available	0,00 €
# 47	2JA-15335-00-00 2JA153350000 2JA153350000	DAMPER 3	Not available	0,00 €
# 48	90480-12314-00 904801249700 904801231400	GROMMET(3AA)	1,78 €
# 49	90387-060L4-00 90387060L400 90387060L400	COLLERETTE	Not available	0,00 €
# 50	90480-12237-00 904801223700 904801223700	GROMMET (2T4)	3,28 €
# 51	90159-06151-00 901590615100 901590615100	SCREW, WITH WASHER(2JA)	Not available	0,00 €
# 52	1GJ-1541F-00-00 1GJ1541F0000 1GJ1541F0000	STAY, COVER 3	Not available	0,00 €
# 53	54V-15484-00-00 54V154840000 54V154840000	CLAMP 2	Not available	0,00 €
# 54	90465-10296-00 904651029600 904651029600	CLAMP(1GJ)	Not available	0,00 €

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CRANKCASE of your Yamaha ACTIVE of 1992. Let us know if you have any questions.
