CRANKCASE FOR YAMAHA ACTIVE 1990

STARTER MOTOR

(1) 2XX-15110-00-00

CRANKCASE ASSY 1

(2) 164-22216-00-00

BUSHING, REAR CUSHION

(3) 93306-00201-00

BRG,R-B 6002RS 32MM 30G KY

(4) 2GM-15120-00-00

CRANKCASE ASSY 2

(5) 93306-00201-00

BRG,R-B 6002RS 32MM 30G KY

(6) 583-15371-00-00

BREATHER

(7) 995301201600

PIN, DOWEL

(9) 985070603500

SCREW, PAN

(10) 958170604000

BOLT, FLANGE

(11) 985800654500

SCREW PAN HEAD

(12) 1GJ-15317-00-00

SPACER, ENGINE MOUNT

(13) 990091540000

CIRCLIP(1AR)

(14) 1HV-15421-01-00

COVER, CRANKCASE 2

(15) 3WX154510000

GASKET, CRANKCASE COVER 1

(16) 99530-10014-00

PIN, DOWEL

(17) 913170603500

BOLT,SOCKET

(18) 913170602000

BOLT,SOCKET

(19) 2GM-W1541-01-00

CRANKCASE COVER ASSY 1

(20) 933006381300

BEARING

(21) 99530-10014-00

PIN, DOWEL

(22) 985170602500

SCREW, PAN HEAD (76T)

(23) 985070603500

SCREW, PAN

(24) 985070607000

SCREW, PAN HEAD

(25) 929070660000

WASHER(6TA)

(26) 4J2153631000

PLUG, OIL

(27) 932101457900

O-RING (26H)

(28) 9010508X1500

BLT,HEX,1/4-20X5/8

(29) 90201-08087-00

WASHER, PLATE 3411117500

(30) 1HV-15128-00-00

HOLDER

(31) 985170601200

SCREW, PAN

(32) 3WX154620000

GASKET, CRANKCASE COVER 3

(33) 24G-15416-00-00

COVER, OIL PUMP

(34) 90159-06075-00

SCREW, WITH WASHER (33A)

(35) 90480-01300-00

GROMMET (5G3)

(36) 90465-20315-00

CLAMP(2GM)

(37) 2XX154710100

DUCT AIR 1

(38) 2GM-15191-00-00

PLATE

(39) 2GM-15407-00-00

ELEMENT 1

(40) 2GM-15408-00-00

ELEMENT 2

(41) 2GM-15472-00-00

SEAL, AIR DUCT

(42) 90176-06065-00

NUT, CROWN(2GM)

(43) 970800604000

BOLT(J52)

(44) 32N-14437-00-00

DUCT

(45) 2XX-15431-00-00

COVER, CRANKCASE 3

(46) 2XX-15316-00-00

DAMPER, ENGINE MOUNT 1

(47) 2JA-15335-00-00

DAMPER 3

(48) 904801249700

GROMMET(3AA)

(49) 903870624100

COLLAR (420)

(50) 90480-12237-00

GROMMET (2T4)

(51) 90159-06151-00

SCREW, WITH WASHER(2JA)

(52) 1GJ-1541F-00-00

STAY, COVER 3

(53) 54V-15484-00-00

CLAMP 2

(54) 90465-10296-00

CLAMP(1GJ)

	Part number	Description	Qty
# 1	2XX-15110-00-00 2XX151100000 2XX151100000	CRANKCASE ASSY 1	Not available	0,00 €
# 2	164-22216-00-00 164222160000 164222160000	BUSHING, REAR CUSHION	8,38 €
# 3	93306-00201-00 933060020100 933060020100	BRG, R-B 6002RS 32MM 30G KY	50,34 €
# 4	2GM-15120-00-00 2GM151200000 2GM151200000	CRANKCASE ASSY 2	Not available	0,00 €
# 5	93306-00201-00 933060020100 933060020100	BRG, R-B 6002RS 32MM 30G KY	50,34 €
# 6	583-15371-00-00 583153710000 583153710000	BREATHER	6,46 €
# 7	99510-12016-00 995301201600 995101201600	PIN, DOWEL	3,43 €
# 9	92501-06035-00 985070603500 925010603500	SCREW, PAN	0,60 €
# 10	95801-06040-00 958170604000 958010604000	BOLT, FLANGE	1,56 €
# 11	98503-06045-00 985800654500 985030604500	SCREW PAN HEAD	4,39 €
# 12	1GJ-15317-00-00 1GJ153170000 1GJ153170000	SPACER, ENGINE MOUNT	Not available	0,00 €
# 13	93440-15012-00 990091540000 934401501200	CIRCLIP(1AR)	3,06 €
# 14	1HV-15421-01-00 1HV154210100 1HV154210100	COVER, CRANKCASE 2	Not available	0,00 €
# 15	27V-15451-03-00 27V154510300	GASKET, CRANKCASE COVER 1	Not available	0,00 €
# 16	99530-10014-00 995301001400 995301001400	PIN, DOWEL	3,06 €
# 17	91316-06035-00 913170603500 913160603500	BOLT, SOCKET	1,37 €
# 18	91316-06020-00 913170602000 913160602000	BOLT, SOCKET	0,36 €
# 19	2GM-W1541-01-00 2GMW15410100 2GMW15410100	CRANKCASE COVER ASSY 1	Not available	0,00 €
# 20	93300-63808-00 933006381300 933006380800	BEARING	39,36 €
# 21	99530-10014-00 995301001400 995301001400	PIN, DOWEL	3,06 €
# 22	98506-06025-00 985170602500 985060602500	SCREW, PAN HEAD (76T)	0,50 €
# 23	98506-06035-00 985070603500 985060603500	SCREW, PAN	0,60 €
# 24	92506-06070-00 985070607000 925060607000	SCREW, PAN HEAD	2,05 €
# 25	92906-06600-00 929070660000 929060660000	WASHER(6TA)	0,60 €
# 26	4J2-15363-00-00 4J2153631000 4J2153630000	PLUG, OIL	5,12 €
# 27	93210-14104-00 932101457900 932101410400	O-RING (26H)	1,56 €
# 28	95801-08016-00 9010508X1500 958010801600	BLT, HEX, 1/4-20X5/8	1,61 €
# 29	90201-08087-00 902010808700 902010808700	WASHER, PLATE 3411117500	3,06 €
# 30	1HV-15128-00-00 1HV151280000 1HV151280000	HOLDER	4,39 €
# 31	98501-06012-00 985010601200	SCREW, PAN	Not available	0,00 €
# 32	14T-15462-00-00 14T154620000	GASKET, CRANKCASE COVER 3	Not available	0,00 €
# 33	24G-15416-00-00 24G154160000 24G154160000	COVER, OIL PUMP	Not available	0,00 €
# 34	90159-06075-00 901590607500 901590607500	SCREW, WITH WASHER (33A)	Not available	0,00 €
# 35	90480-01300-00 904800130000 904800130000	GROMMET (5G3)	Not available	0,00 €
# 36	90465-20315-00 904652031500 904652031500	CLAMP(2GM)	Not available	0,00 €
# 37	2GM-15471-01-00 2GM154710100	DUCT AIR 1	Not available	0,00 €
# 38	2GM-15191-00-00 2GM151910000 2GM151910000	PLATE	Not available	0,00 €
# 39	2GM-15407-00-00 2GM154070000 2GM154070000	ELEMENT 1	Not available	0,00 €
# 40	2GM-15408-00-00 2GM154080000 2GM154080000	ELEMENT 2	Not available	0,00 €
# 41	2GM-15472-00-00 2GM154720000 2GM154720000	SEAL, AIR DUCT	Not available	0,00 €
# 42	90176-06065-00 901760606500 901760606500	NUT, CROWN(2GM)	1,61 €
# 43	97001-06040-00 970800604000 970010604000	BOLT(J52)	4,90 €
# 44	32N-14437-00-00 32N144370000 32N144370000	DUCT	Not available	0,00 €
# 45	2XX-15431-00-00 2XX154310000 2XX154310000	COVER, CRANKCASE 3	Not available	0,00 €
# 46	2XX-15316-00-00 2XX153160000 2XX153160000	DAMPER, ENGINE MOUNT 1	Not available	0,00 €
# 47	2JA-15335-00-00 2JA153350000 2JA153350000	DAMPER 3	Not available	0,00 €
# 48	90480-12314-00 904801249700 904801231400	GROMMET(3AA)	1,78 €
# 49	90387-060M1-00 903870624100 90387060M100	COLLAR (420)	3,28 €
# 50	90480-12237-00 904801223700 904801223700	GROMMET (2T4)	3,28 €
# 51	90159-06151-00 901590615100 901590615100	SCREW, WITH WASHER(2JA)	Not available	0,00 €
# 52	1GJ-1541F-00-00 1GJ1541F0000 1GJ1541F0000	STAY, COVER 3	Not available	0,00 €
# 53	54V-15484-00-00 54V154840000 54V154840000	CLAMP 2	Not available	0,00 €
# 54	90465-10296-00 904651029600 904651029600	CLAMP(1GJ)	Not available	0,00 €
