FUEL TANK FOR YAMAHA PW80 2011

SEAT

Item numbers

FUEL TANK COMP.

3RV241102000 3RV241102000

159,51 €

Unit Price Incl. Tax

GROMMET (4V1)

904801829000 904801829000

6,77 €

Unit Price Incl. Tax

COLLAR (1T2)

903870759800 903870759800

4,27 €

Unit Price Incl. Tax

BOLT, FLANGE

958070603000

958170603000

1,44 €

Unit Price Incl. Tax

BAND, TANK FITTING 1

59V241730000 59V241730000

20,61 €

Unit Price Incl. Tax

CAP ASSY

2FG246100000

2FG246101000

39,21 €

Unit Price Incl. Tax

HOSE (L600)

90445084J100

90445083J500

6,09 €

Unit Price Incl. Tax

FUEL COCK ASSY 1

4X8245000300

23F245001100

92,05 €

Unit Price Incl. Tax

SEAL, COCK

3AJ245340100 3AJ245340100

4,56 €

Unit Price Incl. Tax

SCREW, PAN HEAD(3AC)

985070300800

985170300800

1,14 €

Unit Price Incl. Tax

O-RING

4X8245120000 4X8245120000

3,19 €

Unit Price Incl. Tax

VALVE PACKING

3AC245230000 3AC245230000

13,19 €

Unit Price Incl. Tax

WASHER, PLATE(3MB)

902020519300

902020518700

1,14 €

Unit Price Incl. Tax

SCREW 256241430000

901490601100 901490601100

3,75 €

Unit Price Incl. Tax

HOSE (L420)

904450908200

904450908300

4,23 €

Unit Price Incl. Tax

DAMPER, LOCATING 1

21W241810000 21W241810000

4,82 €

Unit Price Incl. Tax

NOT AVAILABLE

2X6241830000

Not available

CLIP 101235600 10PK

904670800300 904670800300

2,79 €

Unit Price Incl. Tax

GRAPHIC SET

3RV24240G000 3RV24240G000

186,75 €

Unit Price Incl. Tax

WASHER PLATE 137241870000

902010607200 902010607200

3,10 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FUEL TANK of your Yamaha PW80 of 2011. Let us know if you have any questions.
