ELECTRICAL 1 FOR YAMAHA YFM700R 2013

ELECTRICAL 2

Item numbers
ELECTRICAL 1 Yamaha QUAD 700 2013 RAPTOR YFM700RYFM7RSED
1
2
3
4
5
6
7
8
9
10
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
27
28
29
29
30
31
32
32
33
34
35
36
37
38
38
39
40
41
42
42
43
44
45
46
47
48
49
50
51
52
53
54
54
55
56
57
58
59
60
61
62
1
ENGINE CONTROL UNIT ASSY

1S38591A0000  

1S38591A0100
 1S38591A0000

Unit Price Incl. Tax

2
BOLT, BUTTON HEAD

920120601000   920120601000

920120601000

Unit Price Incl. Tax

3
BRACKET, C.D.I. UNIT

1S3212740000   1S3212740000

1S3212740000

Unit Price Incl. Tax

4
BAND

1S3855460000   1S3855460000

1S3855460000

Unit Price Incl. Tax

5
IGNITION COIL ASSY

3TB823100000  

4DN823200000
 3TB823100000

Unit Price Incl. Tax

6
BOLT (2E9)

970020502000  

970210502000
 970020502000

Unit Price Incl. Tax

7
PLUG CAP ASSY

5VK823700000   5VK823700000

5VK823700000

Unit Price Incl. Tax

8
NEUTRAL SWITCH ASSY

5LP825400100   5LP825400100

5LP825400100

Unit Price Incl. Tax

9
NEUTRAL SWITCH ASSY

3GB825400100   3GB825400100

3GB825400100

Unit Price Incl. Tax

10
GASKET (1KH, 1.0T)

904301014800   904301014800

904301014800

Unit Price Incl. Tax

11
THERMOSENSOR ASSY

5PS857900000   5PS857900000

5PS857900000

Unit Price Incl. Tax

12
GASKET(2GH)

904301220200   904301220200

904301220200

Unit Price Incl. Tax

13
SENSOR, SPEED

1S3837550100  

1S3837550200
 1S3837550100

Unit Price Incl. Tax

14
O-RING

4D9811680000   4D9811680000

4D9811680000

Unit Price Incl. Tax

15
BOLT, SOCKET

913120601600  

913120601600
Not available
16
CLAMP

904611000400   904611000400

904611000400

Unit Price Incl. Tax

17
RECTIFIER & REGULATOR ASSY

5BN819600000   5BN819600000

5BN819600000

Unit Price Incl. Tax

18
BOLT, FLANGE

958120602500  

958110602500
 958120602500

Unit Price Incl. Tax

19
BATTERY ASSY
BATTERY ASSY

1PEH21000000  

1PEH21000000
Not available
20
BOX, BATTERY 1

1PEH212B0000   1PEH212B0000

1PEH212B0000

Unit Price Incl. Tax

21
BOLT, FLANGE

901050608400   901050608400

901050608400

Unit Price Incl. Tax

22
BOLT, FLANGE

958020603000  

958210603000
 958020603000

Unit Price Incl. Tax

23
COLLAR

903870615300   903870615300

903870615300

Unit Price Incl. Tax

24
COLLAR

90387063E600  

903870638800
 90387063E600

Unit Price Incl. Tax

25
BRACKET, BATTERY

1PEH21280000   1PEH21280000

1PEH21280000

Unit Price Incl. Tax

26
BOLT, FLANGE

958020602000  

958010602000
 958020602000

Unit Price Incl. Tax

27
SEAT, BATTERY

1S3821230000   1S3821230000

1S3821230000

Unit Price Incl. Tax

28
COVER, BATTERY

1PEH21290000   1PEH21290000

1PEH21290000

Unit Price Incl. Tax

29
PLATE, FOOTREST

4HC274150000   4HC274150000

4HC274150000

Unit Price Incl. Tax

30
DAMPER

22F2139X0000   22F2139X0000

22F2139X0000

Unit Price Incl. Tax

31
PAD, BATTERY

5TG821211000   5TG821211000

5TG821211000

Unit Price Incl. Tax

32
RIVET

902690600200   902690600200

902690600200

Unit Price Incl. Tax

33
WIRE, PLUS LEAD

1PEH21150000   1PEH21150000

1PEH21150000

Unit Price Incl. Tax

34
WIRE, MINUS LEAD

1PEH21160000   1PEH21160000

1PEH21160000

Unit Price Incl. Tax

35
WIRE, LEAD

1S3825410000   1S3825410000

1S3825410000

Unit Price Incl. Tax

36
STARTER RELAY ASSY (2768112-A)

5UG819400000   5UG819400000

5UG819400000

Unit Price Incl. Tax

37
FUSE (12V 30A)

1AE821510000   1AE821510000

1AE821510000

Unit Price Incl. Tax

38
BOLT, FLANGE

950220600800   950220600800

950220600800

Unit Price Incl. Tax

39
MAIN SWITCH ASSY

4SH825100000  

4SH825100100
 4SH825100000

Unit Price Incl. Tax

40
CAP, KEY

3HN825790000   3HN825790000

3HN825790000

Unit Price Incl. Tax

41
NUT, MAIN SWITCH

3HN825690000   3HN825690000

3HN825690000

Unit Price Incl. Tax

42
WIRE HARNESS ASSY

1PE825900000   1PE825900000

1PE825900000

Unit Price Incl. Tax

43
CIRCUIT BREAKER ASSY

3D5821800000   3D5821800000

3D5821800000

Unit Price Incl. Tax

44
THERMO SWITCH ASSY

3D5825600000   3D5825600000

3D5825600000

Unit Price Incl. Tax

45
FUSE (10A)

5JJ821513000  

67F821514000
 5JJ821513000

Unit Price Incl. Tax

46
FUSE

5JJ821512000   5JJ821512000

5JJ821512000

Unit Price Incl. Tax

47
STOP SWITCH ASSY

1S3825301000  

1S3825301000
Not available
48
RELAY ASSY (5VK-30)

5VK819503000  

5VK819503000
Not available
49
RELAY ASSY (5EA-02)

5EA819502000   5EA819502000

5EA819502000

Unit Price Incl. Tax

50
RELAY ASSY

5DM819500000  

5DM819500100
 5DM819500000

Unit Price Incl. Tax

51
SENSOR, LEAN ANGLE

5PS825760100   5PS825760100

5PS825760100

Unit Price Incl. Tax

52
BOLT

913120402500   913120402500

913120402500

Unit Price Incl. Tax

53
NUT, FLANGE

957020450000  

957010450000
 957020450000

Unit Price Incl. Tax

54
WASHER, PLATE

902010403000   902010403000

902010403000

Unit Price Incl. Tax

55
CLAMP(4FM)

904641519500   904641519500

904641519500

Unit Price Incl. Tax

56
CLAMP (6E5)

9046513M1100   9046513M1100

9046513M1100

Unit Price Incl. Tax

57
RESISTOR ASSY

1S3853700000   1S3853700000

1S3853700000

Unit Price Incl. Tax

58
BOLT, FLANGE (29L)

958120601000   958120601000

958120601000

Unit Price Incl. Tax

59
CLAMP

904641601300   904641601300

904641601300

Unit Price Incl. Tax

60
CLAMP

904651009800   904651009800

904651009800

Unit Price Incl. Tax

61
CLAMP

904651009800   904651009800

904651009800

Unit Price Incl. Tax

62
PILOT LIGHT ASSY

1S3835300000  

1S3835300100
 1S3835300000

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 1 of your Yamaha YFM700R of 2013. Let us know if you have any questions.
