REAR WHEEL

REAR WHEEL 2 FOR YAMAHA YFM700FWAD 2012

REAR BRAKE CALIPER

Item numbers

VALVE, RIM

939000081300

939000081200

4,49 €

Unit Price Incl. Tax

NUT

901791002000 901791002000

11,48 €

Unit Price Incl. Tax

HUB ASSY 2

3B4251111000

3B4251111100

186,25 €

Unit Price Incl. Tax

BOLT, SERRATION

901141001400 901141001400

2,52 €

Unit Price Incl. Tax

REAR KNUCKLE ASSY.

1HPF532F0000

2BGF532F0000

317,38 €

Unit Price Incl. Tax

BEARING

933050060200 933050060200

105,19 €

Unit Price Incl. Tax

CIRCLIP

990095550000 990095550000

4,82 €

Unit Price Incl. Tax

BUSH, SOLID(2NL)

903811706700 903811706700

16,75 €

Unit Price Incl. Tax

NIPPLE, GREASE(6A1)

937000600400

9370006M0300

7,75 €

Unit Price Incl. Tax

RING, WHEEL 2 (RIGHT)

3B42515A0000 3B42515A0000

14,56 €

Unit Price Incl. Tax

PLATE 2

3B42539G0000 3B42539G0000

25,06 €

Unit Price Incl. Tax

RIVET, BLIND(8CH)

902674718700 902674718700

2,08 €

Unit Price Incl. Tax

WASHER, PLATE

902010402700 902010402700

1,03 €

Unit Price Incl. Tax

SCREW

901490611700 901490611700

2,00 €

Unit Price Incl. Tax

SPACER

5KM234480000 5KM234480000

37,32 €

Unit Price Incl. Tax

COVER, THRUST 1

2NL235170000

3JN235170000

19,40 €

Unit Price Incl. Tax

BOLT, FLANGE

901051021200 901051021200

8,84 €

Unit Price Incl. Tax

NUT, SELF-LOCKING

901851001200 901851001200

3,87 €

Unit Price Incl. Tax

DOUBLE OFF SET JOINT

28P2530V0100

28P2530V1000

251,73 €

Unit Price Incl. Tax

BALL JOINT SET

28P2510F0200

28P2510F0300

399,60 €

Unit Price Incl. Tax

BOOT SET(DOUBLE OFFSET JOINT)

28P2510H0200

28P2510H1000

69,09 €

Unit Price Incl. Tax

BOOT SET (BALL JOINT)

28P2510G0100

28P2510G1000

69,09 €

Unit Price Incl. Tax

SHAFT

28P2518E1000 28P2518E1000

150,98 €

Unit Price Incl. Tax

BOOT BAND(DOUBLE OFFSET JOINT)

3B42511H0000 3B42511H0000

10,86 €

Unit Price Incl. Tax

BOOT BAND (SMALL)

3B42512G0000 3B42512G0000

8,11 €

Unit Price Incl. Tax

BOOT BAND (SMALL)

28P2512G0000 28P2512G0000

8,57 €

Unit Price Incl. Tax

SNAP RING

3B42512J0000 3B42512J0000

5,35 €

Unit Price Incl. Tax

CIRCLIP

3B42512H0000 3B42512H0000

5,35 €

Unit Price Incl. Tax

CIRCLIP

3B4251820000 3B4251820000

6,09 €

Unit Price Incl. Tax

BOOT BAND(DOUBLE OFFSET JOINT)

28P2511H0000 28P2511H0000

12,15 €

Unit Price Incl. Tax

CLIP, SPRING

3B42536E0000 3B42536E0000

4,61 €

Unit Price Incl. Tax

NUT

901792001600 901792001600

15,92 €

Unit Price Incl. Tax

CAP, WHEEL

1HPF512A0000 1HPF512A0000

3,10 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
