STARTER MOTOR

STARTER CLUTCH FOR YAMAHA YFM700R 2009

TRANSMISSION

Item numbers

GEAR, PRIMARY DRIVE

1S3161110000 1S3161110000

97,10 €

Unit Price Incl. Tax

KEY, STRAIGHT

902820700300 902820700300

8,45 €

Unit Price Incl. Tax

WASHER, LOCK

902152000600 902152000600

3,58 €

Unit Price Incl. Tax

NUT (4X7)

901702027400 901702027400

13,14 €

Unit Price Incl. Tax

PRIMARY DRIVEN GEAR COMP.

1S3161500000 1S3161500000

346,80 €

Unit Price Incl. Tax

PLATE, THRUST 1

2JN161540000 2JN161540000

14,07 €

Unit Price Incl. Tax

BOSS, CLUTCH

1S3163710000 1S3163710000

158,04 €

Unit Price Incl. Tax

PLATE, SEAT

5JG163840000 5JG163840000

47,67 €

Unit Price Incl. Tax

SPRING, CLUTCH BOSS

5JG163830000 5JG163830000

41,56 €

Unit Price Incl. Tax

PLATE, FRICTION 2

5TG163310000 5TG163310000

23,00 €

Unit Price Incl. Tax

PLATE, CLUTCH 2

4X7163250000

Not available

RING, CLUTCH BOSS

4X7163850000 4X7163850000

6,77 €

Unit Price Incl. Tax

PLATE, FRICTION

5TA163210000 5TA163210000

22,74 €

Unit Price Incl. Tax

PLATE, CLUTCH 2

4X7163250000

Not available

PLATE, PRESSURE 1

1S3163510000 1S3163510000

118,71 €

Unit Price Incl. Tax

BEARING(2JN)

933060030400

933060031500

43,19 €

Unit Price Incl. Tax

SPRING, COMPRESSION(3GM)

90501230E400 90501230E400

5,85 €

Unit Price Incl. Tax

SCREW, WITH WASHER

901590602900 901590602900

1,40 €

Unit Price Incl. Tax

WASHER, CONICAL SPRING

902082000100 902082000100

17,84 €

Unit Price Incl. Tax

NUT

901792000700 901792000700

18,17 €

Unit Price Incl. Tax

ROD, PUSH 1

4XV163560100 4XV163560100

59,19 €

Unit Price Incl. Tax

PUSH LEVER ASSY

3LD163400100 3LD163400100

30,90 €

Unit Price Incl. Tax

SPRING, TORSION

905081801800 905081801800

4,23 €

Unit Price Incl. Tax

AXLE, PUSH LEVER

5EB163820000 5EB163820000

103,05 €

Unit Price Incl. Tax

WASHER, PLAIN (663) 5PK

929020860000

929900860000

1,14 €

Unit Price Incl. Tax

CIRCLIP(6L2) 5PK

990010760000

990800760000

1,14 €

Unit Price Incl. Tax

BEARING

933171102000

933171109600

11,03 €

Unit Price Incl. Tax

OIL SEAL (3X3)

931021521200 931021521200

12,32 €

Unit Price Incl. Tax

BRG, CYL-CAL ROLLER 16G TM

933153150200 933153150200

29,51 €

Unit Price Incl. Tax

WASHER, PLATE (2W5)

902011061400 902011061400

4,44 €

Unit Price Incl. Tax

CIRCLIP(10W)

990091040000 990091040000

1,14 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
