STEERING

FRONT FORK FOR YAMAHA XSR 700 35KW A2 2024

FUEL TANK

Item numbers

FRONT FORK ASSY (R.H)

BJV231030000 BJV231030000

613,04 €

Unit Price Incl. Tax

TUBE, OUTER 2

BAT231360000 BAT231360000

330,27 €

Unit Price Incl. Tax

INNER TUBE COMP.1

1WS231100000 1WS231100000

259,36 €

Unit Price Incl. Tax

PISTON, FRONT FORK

5BN231710000 5BN231710000

21,37 €

Unit Price Incl. Tax

CYLINDER COMP., FRONT FORK

1WS231700000 1WS231700000

149,22 €

Unit Price Incl. Tax

METAL, SLIDE 1

4FM231254000 4FM231254000

27,50 €

Unit Price Incl. Tax

WASHER, OIL SEAL

36Y231461000 36Y231461000

10,86 €

Unit Price Incl. Tax

OIL SEAL

4EB231450100 4EB231450100

18,97 €

Unit Price Incl. Tax

CLIP, OIL SEAL

26H231560000 26H231560000

4,23 €

Unit Price Incl. Tax

SEAL, DUST

4EB231440000 4EB231440000

26,22 €

Unit Price Incl. Tax

SPINDLE, TAPER

4YR231730000 4YR231730000

37,65 €

Unit Price Incl. Tax

GASKET

50923158L000 50923158L000

2,72 €

Unit Price Incl. Tax

BOLT, HEXAGON SOCKET HEAD

278231815000

3D8231810000

11,12 €

Unit Price Incl. Tax

SPRING, FRONT FORK

1WS231410100 1WS231410100

73,37 €

Unit Price Incl. Tax

WASHER, SPRING UPPER

3EN231495000 3EN231495000

4,23 €

Unit Price Incl. Tax

SPACER

3FW231180000 3FW231180000

17,59 €

Unit Price Incl. Tax

BOLT, CAP

1D0231110000 1D0231110000

70,36 €

Unit Price Incl. Tax

O-RING

43F231881100 43F231881100

3,41 €

Unit Price Incl. Tax

BOLT, SOCKET

913140804000 913140804000

3,10 €

Unit Price Incl. Tax

FRONT FORK ASSY (L.H)

BJV231020000 BJV231020000

613,04 €

Unit Price Incl. Tax

TUBE, OUTER (L.H)

BAT231260000 BAT231260000

330,27 €

Unit Price Incl. Tax

INNER TUBE COMP.1

1WS231100000 1WS231100000

259,36 €

Unit Price Incl. Tax

PISTON, FRONT FORK

5BN231710000 5BN231710000

21,37 €

Unit Price Incl. Tax

CYLINDER COMP., FRONT FORK

1WS231700000 1WS231700000

149,22 €

Unit Price Incl. Tax

METAL, SLIDE 1

4FM231254000 4FM231254000

27,50 €

Unit Price Incl. Tax

WASHER, OIL SEAL

36Y231461000 36Y231461000

10,86 €

Unit Price Incl. Tax

OIL SEAL

4EB231450100 4EB231450100

18,97 €

Unit Price Incl. Tax

CLIP, OIL SEAL

26H231560000 26H231560000

4,23 €

Unit Price Incl. Tax

SEAL, DUST

4EB231440000 4EB231440000

26,22 €

Unit Price Incl. Tax

SPINDLE, TAPER

4YR231730000 4YR231730000

37,65 €

Unit Price Incl. Tax

GASKET

50923158L000 50923158L000

2,72 €

Unit Price Incl. Tax

BOLT, HEXAGON SOCKET HEAD

278231815000

3D8231810000

11,12 €

Unit Price Incl. Tax

SPRING, FRONT FORK

1WS231410100 1WS231410100

73,37 €

Unit Price Incl. Tax

WASHER, SPRING UPPER

3EN231495000 3EN231495000

4,23 €

Unit Price Incl. Tax

SPACER

3FW231180000 3FW231180000

17,59 €

Unit Price Incl. Tax

BOLT, CAP

1D0231110000 1D0231110000

70,36 €

Unit Price Incl. Tax

O-RING

43F231881100 43F231881100

3,41 €

Unit Price Incl. Tax

UNDER BRACKET COMP.

B34233400000 B34233400000

511,98 €

Unit Price Incl. Tax

SEAL, STEERING

3FV234620000 3FV234620000

17,59 €

Unit Price Incl. Tax

BEARING(3FV)

933999993200 933999993200

68,92 €

Unit Price Incl. Tax

BOLT, SOCKET

913140803000 913140803000

2,00 €

Unit Price Incl. Tax

COVER

1WS2331G0000 1WS2331G0000

10,86 €

Unit Price Incl. Tax

COVER, LOWER 1

4KM231230100 4KM231230100

22,74 €

Unit Price Incl. Tax

FORK SEALS KIT

BATW003B0000 BATW003B0000

65,14 €

Unit Price Incl. Tax

REFLECTOR FRONT 1

2FCH51110000 2FCH51110000

13,70 €

Unit Price Incl. Tax

BRACKET, REFLECTOR

B0KH51120000 B0KH51120000

14,69 €

Unit Price Incl. Tax

BRACKET, REFLECTOR

BJVH51220000 BJVH51220000

17,71 €

Unit Price Incl. Tax

NUT, FLANGE(3GM)

957070550000 957070550000

1,89 €

Unit Price Incl. Tax

CAP

BC3283490000 BC3283490000

2,23 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FRONT FORK of your Yamaha XSR 700 35KW A2 of 2024. Let us know if you have any questions.
