STAND / FOOTREST FOR YAMAHA XSR 700 LEGACY 2023

STAND / FOOTREST 2

Item numbers

BRACKET ADAPTER 1

B34274A30000

Not available

BOLT

901111006000

901111000600

5,26 €

Unit Price Incl. Tax

STAND, SIDE

BAT273110000 BAT273110000

80,05 €

Unit Price Incl. Tax

BOLT

901011002500 901011002500

8,57 €

Unit Price Incl. Tax

WASHER, PLATE

902011701800 902011701800

1,44 €

Unit Price Incl. Tax

COLLAR

903871005000 903871005000

7,93 €

Unit Price Incl. Tax

WASHER, PLATE

902011003500 902011003500

2,12 €

Unit Price Incl. Tax

NUT, SELF-LOCKING

901851002300 901851002300

5,35 €

Unit Price Incl. Tax

SPRING, TENSION

905062301800 905062301800

15,49 €

Unit Price Incl. Tax

GUIDE, SIDE STAND

5VX273510000 5VX273510000

4,78 €

Unit Price Incl. Tax

LINK, SIDE STAND

5VX273150000 5VX273150000

4,23 €

Unit Price Incl. Tax

SWITCH, SIDE STAND

1WS825660000

Not available

HOLDER

1WS2419A0000 1WS2419A0000

9,74 €

Unit Price Incl. Tax

BOLT, HEXAGON SOCKET HEAD

901100507100 901100507100

1,40 €

Unit Price Incl. Tax

NUT, U FLANGE

956020520000

956010520000

2,90 €

Unit Price Incl. Tax

BRACKET, SIDE STAND

1WS273210000 1WS273210000

91,97 €

Unit Price Incl. Tax

BOLT, HEX. SOCKET BUTTON

901111005800

901111005900

4,08 €

Unit Price Incl. Tax

FOOTREST

1RC274510000 1RC274510000

32,91 €

Unit Price Incl. Tax

PIN, CLEVIS

917010804000

917020804000

8,31 €

Unit Price Incl. Tax

PIN, COTTER 5PK

914022501500

914012501500

2,00 €

Unit Price Incl. Tax

SPRING, TORSION

9050818X0000 9050818X0000

13,62 €

Unit Price Incl. Tax

COVER, FOOTREST

23P274130000 23P274130000

34,43 €

Unit Price Incl. Tax

BOLT

9010908X1300 9010908X1300

27,87 €

Unit Price Incl. Tax

BRACKET 2

1WS274421000 1WS274421000

131,93 €

Unit Price Incl. Tax

DAMPER, FOOTREST

36Y274140000 36Y274140000

22,53 €

Unit Price Incl. Tax

STOPPER, MAIN STAND

5VX271140000 5VX271140000

2,98 €

Unit Price Incl. Tax

JOINT, ROD 1

5VX181160000 5VX181160000

62,88 €

Unit Price Incl. Tax

COVER, DUST

5VX181540000 5VX181540000

5,26 €

Unit Price Incl. Tax

PLATE 1

B4TF74450000 B4TF74450000

41,25 €

Unit Price Incl. Tax

BOLT, BUTTON HEAD(3JP)

920140601200 920140601200

1,40 €

Unit Price Incl. Tax

SHIFT PEDAL ASSY

BAT181100000 BAT181100000

138,60 €

Unit Price Incl. Tax

COVER, SHIFT PEDAL

1WS181130000 1WS181130000

5,52 €

Unit Price Incl. Tax

WASHER, PLATE

902011205100 902011205100

1,89 €

Unit Price Incl. Tax

WASHER, WAVE (17W)

902061207400 902061207400

2,08 €

Unit Price Incl. Tax

BOLT

4BP274340100

4BP274341100

3,58 €

Unit Price Incl. Tax

WASHER, PLATE

902010805300 902010805300

2,68 €

Unit Price Incl. Tax

ROD, SHIFT

5A8181150000 5A8181150000

32,12 €

Unit Price Incl. Tax

NUT

901700602600 901700602600

1,14 €

Unit Price Incl. Tax

NUT

953140670000 953140670000

1,11 €

Unit Price Incl. Tax

BOLT, HEXAGON SOCKET HEAD(38V)

901100807100 901100807100

3,41 €

Unit Price Incl. Tax

WASHER(1UF)

902090829500 902090829500

8,93 €

Unit Price Incl. Tax

COLLAR

903870637200

903870602200

1,93 €

Unit Price Incl. Tax

BOLT, BUTTON HEAD

901110609800

920120602000

1,29 €

Unit Price Incl. Tax

COVER 1

B34F74531000 B34F74531000

98,51 €

Unit Price Incl. Tax

GROMMET

904801400300 904801400300

3,46 €

Unit Price Incl. Tax

COLLAR

903870605700 903870605700

3,58 €

Unit Price Incl. Tax

SCREW(4DN)

901490630200 901490630200

6,38 €

Unit Price Incl. Tax

RIVET

902690800800 902690800800

2,08 €

Unit Price Incl. Tax

FOOTREST, REAR 1

BJVF74310000 BJVF74310000

38,88 €

Unit Price Incl. Tax

BRACKET 4

BJVF741L0000 BJVF741L0000

131,06 €

Unit Price Incl. Tax

SPRING, COMPRESSION (22N)

905011274300 905011274300

5,60 €

Unit Price Incl. Tax

BALL 5PK

935010401100 935010401100

0,98 €

Unit Price Incl. Tax

WASHER, SPECIAL

5VX274370000 5VX274370000

8,02 €

Unit Price Incl. Tax

PIN, WITH HOLE (2G2)

902400806300 902400806300

5,18 €

Unit Price Incl. Tax

PIN, COTTER 5PK

914012501500

914012502000

2,00 €

Unit Price Incl. Tax

BOLT, FLANGE

901050805300 901050805300

10,91 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
