STARTER MOTOR

STARTER CLUTCH FOR YAMAHA XSR 700 A2 35KW 2022

TRANSMISSION

Item numbers

PRIMARY DRIVEN GEAR COMP.

1WS161500000 1WS161500000

774,57 €

Unit Price Incl. Tax

PLATE, THRUST

363161540000 363161540000

12,32 €

Unit Price Incl. Tax

BOSS, CLUTCH

1WS163710100 1WS163710100

309,58 €

Unit Price Incl. Tax

PLATE, FRICTION

5VY163210000 5VY163210000

22,58 €

Unit Price Incl. Tax

PLATE, CLUTCH 2

5VY163250000

Not available

PLATE, FRICTION

5TG163210000 5TG163210000

17,29 €

Unit Price Incl. Tax

PRESSURE PLATE ASSY

1WS163500000 1WS163500000

102,88 €

Unit Price Incl. Tax

BRG, R-B 6001 28MM 28G KY

933060010600

933060010500

18,68 €

Unit Price Incl. Tax

SPRING, COMPRESSION(3GM)

90501230E400 90501230E400

5,85 €

Unit Price Incl. Tax

BOLT, WITH WASHER

901190626300 901190626300

3,87 €

Unit Price Incl. Tax

SPACER 1

BU3E61810000 BU3E61810000

12,32 €

Unit Price Incl. Tax

BEARING

93310332X900 93310332X900

11,86 €

Unit Price Incl. Tax

PLATE, THRUST

363161540000 363161540000

12,32 €

Unit Price Incl. Tax

WASHER, PLATE

902012003000 902012003000

9,14 €

Unit Price Incl. Tax

WASHER, CONICAL SPRING

902082000100 902082000100

17,84 €

Unit Price Incl. Tax

NUT

901792000700 901792000700

18,17 €

Unit Price Incl. Tax

ROD PUSH 1

1WDE63560000 1WDE63560000

11,56 €

Unit Price Incl. Tax

PUSH LEVER ASSY

BU3E63400000 BU3E63400000

23,92 €

Unit Price Incl. Tax

SPRING, TORSION

905081813200 905081813200

3,32 €

Unit Price Incl. Tax

WASHER, PLATE

902011002900 902011002900

2,12 €

Unit Price Incl. Tax

CIRCLIP(10W)

990091040000 990091040000

1,14 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha XSR 700 A2 35KW of 2022. Let us know if you have any questions.
