ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA XSR 700 60TH ANNIVERSARY 2016

ELECTRICAL 3

Item numbers
ELECTRICAL 2 Yamaha MOTO 700 2016 XSR MTM690-U
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
1
SENSOR, PRESSURE

1WS823800000   1WS823800000

1WS823800000

Unit Price Incl. Tax

2
BOLT, SOCKET

913120502000  

913170502000
 913120502000

Unit Price Incl. Tax

3
IGNITION COIL ASSY

1WS823100000   1WS823100000

1WS823100000

Unit Price Incl. Tax

4
NEUTRAL SWITCH ASSY SUPERSEDED

1WS825400000  

1WS825400000
Not available
5
O-RING

932102100100   932102100100

932102100100

Unit Price Incl. Tax

6
BOLT, HEXAGON SOCKET HEAD

901100506700  

901100503800
 901100506700

Unit Price Incl. Tax

7
THERMO UNIT

4P9835910000   4P9835910000

4P9835910000

Unit Price Incl. Tax

8
GASKET

904301000400   904301000400

904301000400

Unit Price Incl. Tax

9
OIL PRESSURE SWITCH ASSY

1WS825040000  

1WS825040000
Not available
10
LEAD WIRE ASSY

1WS813150000   1WS813150000

1WS813150000

Unit Price Incl. Tax

11
PLUG, BLIND

3P6153990000   3P6153990000

3P6153990000

Unit Price Incl. Tax

12
O-RING (22U) 5PK

932101556600   932101556600

932101556600

Unit Price Incl. Tax

13
BOLT, SOCKET

913120601600  

913120601600
Not available
14
WIRE SUB LEAD

1XB823090000  

B2G823090000
 1XB823090000

Unit Price Incl. Tax

15
BAND

B34H55460000   B34H55460000

B34H55460000

Unit Price Incl. Tax

16
MAIN SW. IMMOBILIZER KIT

B34W82501000   B34W82501000

B34W82501000

Unit Price Incl. Tax

17
ENGINE CONTROL UNIT ASSY

B348591A1000   B348591A1000

B348591A1000

Unit Price Incl. Tax

18
IMMOBILIZER. UNIT COMP.

1WS8255P0000  

1WS8255P0000
Not available
19
SCREW

5SL821130100   5SL821130100

5SL821130100

Unit Price Incl. Tax

20
BLANK KEY

5SL825110800   5SL825110800

5SL825110800

Unit Price Incl. Tax

21
BOLT

901090819500  

901090819600
 901090819500

Unit Price Incl. Tax

22
BAND, SWITCH CORD

9046513M2400  

437839361100
 9046513M2400

Unit Price Incl. Tax

23
COVER CONNECTER

B34H16620000   B34H16620000

B34H16620000

Unit Price Incl. Tax

24
BAND, SWITCH CORD

4KHH39360100   4KHH39360100

4KHH39360100

Unit Price Incl. Tax

25
CLAMP(4GL)

904641023300   904641023300

904641023300

Unit Price Incl. Tax

26
FLASHER RELAY ASSY

3XV833502100  

3XV833502200
 3XV833502100
27
HORN

1WS833710000   1WS833710000

1WS833710000

Unit Price Incl. Tax

28
NUT, FLANGE(4MV)

957070650000   957070650000

957070650000

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
