ELECTRICAL 1 FOR YAMAHA XT660Z 2013

ELECTRICAL 2

Item numbers
ELECTRICAL 1 Yamaha MOTO 660 2013 XTZ TENERE XT660Z
1
2
3
4
4
5
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
26
27
28
29
30
31
32
33
1
BOLT HEX SOCKET BUTTON

9011106X1900   9011106X1900

9011106X1900

Unit Price Incl. Tax

2
NUT, FLANGE(7NB)

9570L0650000  

957800650000
 9570L0650000

Unit Price Incl. Tax

3
IGNITION COIL ASSY

4GV823100000  

4DN823200000
 4GV823100000

Unit Price Incl. Tax

4
BOLT

9131M0502000   9131M0502000

9131M0502000
Not available
5
WASHER, PLAIN 5PK

9290M0560000   9290M0560000

9290M0560000

Unit Price Incl. Tax

6
BRACKET, UNIT

11DH59910000   11DH59910000

11DH59910000

Unit Price Incl. Tax

7
COLLAR

903870620200   903870620200

903870620200

Unit Price Incl. Tax

8
NUT, U FLANGE

956070620000  

956020620000
 956070620000

Unit Price Incl. Tax

9
PLUG CAP ASSY

5VK823700000   5VK823700000

5VK823700000

Unit Price Incl. Tax

10
RECTIFIER & REGULATOR ASSY

4XY819600000   4XY819600000

4XY819600000

Unit Price Incl. Tax

11
WASHER PLATE 137241870000

902010607200   902010607200

902010607200

Unit Price Incl. Tax

12
GROMMET (29L)

904801536300   904801536300

904801536300

Unit Price Incl. Tax

13
BOLT, FLANGE

958070604000  

958170604000
 958070604000

Unit Price Incl. Tax

14
COLLAR

903870604200   903870604200

903870604200

Unit Price Incl. Tax

15
BATTERY (GT9B-4)

5FL821000100  

5FL821000100
Not available
16
BRACKET, REGULATOR

11DF12870000   11DF12870000

11DF12870000

Unit Price Incl. Tax

17
WIRE, PLUS LEAD

5YK821150000   5YK821150000

5YK821150000

Unit Price Incl. Tax

18
WIRE, MINUS LEAD

11DH21160000   11DH21160000

11DH21160000

Unit Price Incl. Tax

19
MAIN SW. IMMOBILIZER KIT

11DW82501000  

11DW82501000
Not available
20
ENGINE CONTROL UNIT ASSY

11D8591A0000   11D8591A0000

11D8591A0000

Unit Price Incl. Tax

21
IMMOBILIZER. UNIT COMP.

5YK8255P0000   5YK8255P0000

5YK8255P0000

Unit Price Incl. Tax

22
SCREW

5SL821130100   5SL821130100

5SL821130100

Unit Price Incl. Tax

23
BLANK KEY

5SL825110800   5SL825110800

5SL825110800

Unit Price Incl. Tax

24
BOLT

901090819500  

901090819600
 901090819500

Unit Price Incl. Tax

25
COVER, MAIN SWITCH

11DH25680000   11DH25680000

11DH25680000

Unit Price Incl. Tax

26
BOLT

901110501100   901110501100

901110501100

Unit Price Incl. Tax

27
WIRE HARNESS ASSY

11DH25900100   11DH25900100

11DH25900100

Unit Price Incl. Tax

28
FUSE

5JJ821512000   5JJ821512000

5JJ821512000

Unit Price Incl. Tax

29
FUSE (10A)

5JJ821513000  

67F821514000
 5JJ821513000

Unit Price Incl. Tax

30
FUSE (7.5A-BL)

5JJ821510000   5JJ821510000

5JJ821510000

Unit Price Incl. Tax

31
CLAMP(6J8)

9046432X0000   9046432X0000

9046432X0000

Unit Price Incl. Tax

32
CLAMP 10PK

9046490X0000   9046490X0000

9046490X0000

Unit Price Incl. Tax

33
CLAMP

904642500400   904642500400

904642500400

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 1 of your Yamaha XT660Z of 2013. Let us know if you have any questions.
