FUEL TANK

SEAT FOR YAMAHA XTR 660 2010

FRONT WHEEL

Item numbers

COVER, SEAT

5VK247311100 5VK247311100

112,74 €

Unit Price Incl. Tax

BRACKET, SEAT

4HM247280000 4HM247280000

10,91 €

Unit Price Incl. Tax

NUT, FLANGE(7NB)

901790663500

957010650000

2,23 €

Unit Price Incl. Tax

NOT AVAILABLE

5VKF47703000

Not available

NOT AVAILABLE

5VK247313000

Not available

BRACKET, SEAT

4HM247280000 4HM247280000

10,91 €

Unit Price Incl. Tax

NUT, FLANGE(7NB)

901790663500

957010650000

2,23 €

Unit Price Incl. Tax

DAMPER, SEAT

5VK247370000 5VK247370000

4,00 €

Unit Price Incl. Tax

SEAT LOCK ASSY

4BP247800000 4BP247800000

70,97 €

Unit Price Incl. Tax

PLATE

5VKF47920000 5VKF47920000

15,92 €

Unit Price Incl. Tax

NUT, FLANGE(4MV)

957070650000 957070650000

5,82 €

Unit Price Incl. Tax

WIRE SEAT LOCK

5VKF478E0000 5VKF478E0000

38,36 €

Unit Price Incl. Tax

SEAT LOCK ASSY

2TVW24700000

3CKW24700000

86,43 €

Unit Price Incl. Tax

BOLT, FLANGE

950270601400

950220601400

0,98 €

Unit Price Incl. Tax

BRACKET SEAT LOCK

5VKF478X0000 5VKF478X0000

29,42 €

Unit Price Incl. Tax

DAMPER, SEAT

5VK247470000 5VK247470000

1,89 €

Unit Price Incl. Tax

PAD, SEAT

3VLF47411000 3VLF47411000

6,09 €

Unit Price Incl. Tax

ASSIST GRIP

5VKF474A1000 5VKF474A1000

75,65 €

Unit Price Incl. Tax

ASSIST GRIP

5VKF474W1000 5VKF474W1000

75,65 €

Unit Price Incl. Tax

BOLT, HEXAGON HEAD

9011008X0200 9011008X0200

5,35 €

Unit Price Incl. Tax

SOCKET HEAD

9011008X0600 9011008X0600

10,38 €

Unit Price Incl. Tax

NOT AVAILABLE

5VKF81001000

Not available

TOOL SPECIAL

5VKF81160000 5VKF81160000

18,13 €

Unit Price Incl. Tax

XT660 X&R '07

5VKF8199F100 5VKF8199F100

48,65 €

Unit Price Incl. Tax

XT660 X&R '07

5VKF8199G100 5VKF8199G100

48,65 €

Unit Price Incl. Tax

XT660 X&R '07

5VKF8199H100 5VKF8199H100

48,65 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
