ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA DIVERSION 600 2011

MAIN SW. IMMOBILIZER KIT

36CW82501000 36CW82501000

1 697,74 €

Unit Price Incl. Tax

ENGINE CONTROL UNIT ASSY

20S8591A0000 20S8591A0000

1 433,17 €

Unit Price Incl. Tax

NOT AVAILABLE

1B38255P0000

Not available

SCREW

5SL821130100 5SL821130100

2,68 €

Unit Price Incl. Tax

BLANK KEY

5SL825110800 5SL825110800

93,90 €

Unit Price Incl. Tax

BATTERY (GT12B-4)

4TX821000200 4TX821000200

171,67 €

Unit Price Incl. Tax

STARTER RELAY ASSY (RC19-015)

4SV819401200 4SV819401200

124,41 €

Unit Price Incl. Tax

FUSE (12V 30A)

1AE821510000 1AE821510000

2,79 €

Unit Price Incl. Tax

COVER, LEAD WIRE

20S821190000 20S821190000

16,41 €

Unit Price Incl. Tax

BOLT, FLANGE

950220600800 950220600800

1,03 €

Unit Price Incl. Tax

WIRE, PLUS LEAD

20S821150000 20S821150000

24,43 €

Unit Price Incl. Tax

BATTERY COVER ASSY

20S821600000 20S821600000

26,65 €

Unit Price Incl. Tax

DAMPER

5VK217460000 5VK217460000

1,89 €

Unit Price Incl. Tax

DAMPER

5HN2139X0000 5HN2139X0000

1,44 €

Unit Price Incl. Tax

DAMPER, PLATE

905201500200 905201500200

2,48 €

Unit Price Incl. Tax

SEAT, BATTERY

20S821220100 20S821220100

88,03 €

Unit Price Incl. Tax

WIRE HARNESS ASSY

36C825900000 36C825900000

1 198,52 €

Unit Price Incl. Tax

FUSE

5JJ821512000 5JJ821512000

4,70 €

Unit Price Incl. Tax

FUSE (10A)

5JJ821513000

67F821514000

11,05 €

Unit Price Incl. Tax

FUSE (7.5A-BL)

5JJ821510000 5JJ821510000

4,70 €

Unit Price Incl. Tax

BOLT, SOCKET

913800601200 913800601200

2,90 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307700

904641307300

3,10 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307700

904641307300

3,10 €

Unit Price Incl. Tax

CLAMP

904642001000 904642001000

2,84 €

Unit Price Incl. Tax

CLAMP(4KJ)

904642021300 904642021300

5,18 €

Unit Price Incl. Tax

CLAMP

904642001000 904642001000

2,84 €

Unit Price Incl. Tax

CLAMP(4FM)

904641519500 904641519500

3,10 €

Unit Price Incl. Tax

RECTIFIER & REGULATOR ASSY

5SL819600000 5SL819600000

399,06 €

Unit Price Incl. Tax

RELAY ASSY (5VK-40)

5VK819504000

Not available

RELAY ASSY (5JJ-20)

5JJ819502000 5JJ819502000

104,89 €

Unit Price Incl. Tax

HOLDER, RELAY

5JJ819520000 5JJ819520000

7,93 €

Unit Price Incl. Tax

SENSOR, LEAN ANGLE

5PS825760100 5PS825760100

123,62 €

Unit Price Incl. Tax

SCREW, ROUND TAPPING

901600400900 901600400900

1,22 €

Unit Price Incl. Tax

WASHER, PLATE

902010403000 902010403000

1,29 €

Unit Price Incl. Tax

BOLT

901090819500

901090819600

6,09 €

Unit Price Incl. Tax

CLAMP

904651501100 904651501100

2,68 €

Unit Price Incl. Tax

FLASHER RELAY ASSY

3XV833502100

3XV833502200

HORN

20S833710000 20S833710000

65,66 €

Unit Price Incl. Tax

NUT, FLANGE

957020850000

957010850000

2,19 €

Unit Price Incl. Tax

BRACKET, REAR STAY 2

20S216890000 20S216890000

13,05 €

Unit Price Incl. Tax

GROMMET

904801600700 904801600700

4,00 €

Unit Price Incl. Tax

COLLAR(J45) 5PK

90387064T300 90387064T300

2,41 €

Unit Price Incl. Tax

NUT, FLANGE(7NB)

957020650000

957010650000

2,23 €

Unit Price Incl. Tax

BRACKET, HORN

20S233770000 20S233770000

27,54 €

Unit Price Incl. Tax

BOLT, FLANGE

958020601600

958010601600

1,44 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 2 of your Yamaha DIVERSION 600 of 2011. Let us know if you have any questions.
