COVER - ENGINE 1

STARTER MOTOR FOR YAMAHA TT600R 2001

STARTER CLUTCH

(1) 5Y1-15660-01

KICK CRANK ASSY

(2) 34K-15641-00

GEAR, KICK

(3) 90201-20685

WASHER, PLATE (2K7)

(4) 9341020038

CIRCLIP

(5) 5Y1-15671-01

WHEEL, RATCHET

(6) 90501-16107

SPRING COMPRESSION168156750000

(7) 90201-155K6

WASHER, PLAIN (1JL)

(8) 990091540000

CIRCLIP

(9) 90508-32529

SPRING, TORSION (5Y1)

(10) 90201-15701

WASHER (566)

(11) 2NX-15668-00

STOPPER

(12) 2NX-15674-00

GUIDE, RATCHET WHEEL

(13) 214-15686-00

WASHER, LOCK

(14) 970170601600

BOLT, HEXAGON

(15) 248-15668-00

STOPPER, KICK SPRING

(16) 931022081400

OIL SEAL

(17) 5Y1-15651-01

GEAR, SPR0CKET IDLE 31T

(18) 90201-20276

WASHER PLATE 328171160000

(19) 99009-20400

CIRCLIP(1AR)

(20) 5Y1-15620-02

KICK CRANK ASSY

(21) 5Y1-15621-01

BOSS, KICK CRANK

(22) 905011208100

SPRING COMPRESSION278156220000

(23) 935073203100

BALL (12R)

(24) 90152-06010

SCREW, COUNTERSUNK (5Y1)

(25) 90336-18038

PLUG, TAPER (5Y1)

(26) 9701L-08030

BOLT

(27) 3Y1-1561A-02

LEVER DECOMP ASSY

(28) 93102-10207

SEAL,OIL(SD 10-21-5 HS,3Y1)

(29) 90201105J400

WASHER, PLATE(52H)

(30) 99009-10400

CIRCLIP(10W)

(31) 90508-14524

SPRING, TORSION (5Y1)

(32) 5Y1-1561G-00

LEVER, CABLE

(33) 92907-06600

WASHER(6TA)

(34) 95317-06700

NUT(JN5)

	Part number	Description	Qty
# 1	5Y1-15660-01 5Y11566001 5Y11566001	KICK CRANK ASSY	Not available	0,00 €
# 2	34K-15641-00 34K1564100 34K1564100	GEAR, KICK	Not available	0,00 €
# 3	90201-20685 9020120685 9020120685	WASHER, PLATE (2K7)	4,85 €
# 4	9341020038 9341020038 9341020038	CIRCLIP	Not available	0,00 €
# 5	5Y1-15671-01 5Y11567101 5Y11567101	WHEEL, RATCHET	75,17 €
# 6	90501-16107 9050116107 9050116107	SPRING COMPRESSION168156750000	3,80 €
# 7	90201-155K6 90201155K6 90201155K6	WASHER, PLAIN (1JL)	2,14 €
# 8	9900915400 9900915400	CIRCLIP	Not available	0,00 €
# 9	90508-32529 9050832529 9050832529	SPRING, TORSION (5Y1)	Not available	0,00 €
# 10	90201-15701 9020115701 9020115701	WASHER (566)	3,62 €
# 11	2NX-15668-00 2NX1566800 2NX1566800	STOPPER	15,50 €
# 12	2NX-15674-00 2NX1567400 2NX1567400	GUIDE, RATCHET WHEEL	8,38 €
# 13	214-15686-00 2141568600 2141568600	WASHER, LOCK	3,43 €
# 14	97027-06016 970170601600 9702706016	BOLT, HEXAGON	0,60 €
# 15	248-15668-00 2481566800 2481566800	STOPPER, KICK SPRING	4,76 €
# 16	93102-20108 931022081400 9310220108	OIL SEAL	16,42 €
# 17	5Y1-15651-01 5Y11565101 5Y11565101	GEAR, SPR0CKET IDLE 31T	Not available	0,00 €
# 18	90201-20276 9020120276 9020120276	WASHER PLATE 328171160000	5,50 €
# 19	99009-20400 9900920400 9900920400	CIRCLIP(1AR)	4,16 €
# 20	5Y1-15620-02 5Y11562002 5Y11562002	KICK CRANK ASSY	293,50 €
# 21	5Y1-15621-01 5Y11562101 5Y11562101	BOSS, KICK CRANK	136,21 €
# 22	905011208100 905011208100 905011208100	SPRING COMPRESSION278156220000	2,19 €
# 23	93507-32009 935073203100 9350732009	BALL (12R)	0,50 €
# 24	90152-06010 9015206010 9015206010	SCREW, COUNTERSUNK (5Y1)	0,96 €
# 25	90336-18038 9033618038 9033618038	PLUG, TAPER (5Y1)	Not available	0,00 €
# 26	9701L-08030 9701L08030 9701L08030	BOLT	Not available	0,00 €
# 27	3Y1-1561A-02 3Y11561A02 3Y11561A02	LEVER DECOMP ASSY	Not available	0,00 €
# 28	93102-10207 9310210207 9310210207	SEAL, OIL(SD 10-21-5 HS, 3Y1)	12,02 €
# 29	90201-10135 90201105J400 9020110135	WASHER, PLATE(52H)	2,41 €
# 30	99009-10400 9900910400 9900910400	CIRCLIP(10W)	0,60 €
# 31	90508-14524 9050814524 9050814524	SPRING, TORSION (5Y1)	Not available	0,00 €
# 32	5Y1-1561G-00 5Y11561G00 5Y11561G00	LEVER, CABLE	9,37 €
# 33	92907-06600 9290706600 9290706600	WASHER(6TA)	0,60 €
# 34	95317-06700 9531706700 9531706700	NUT(JN5)	0,60 €

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
