Displacement

Year

Model

Finish line

Parts catalogue

Parts diagram

ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA TMAX 530 2016

Item numbers
ELECTRICAL 2 Yamaha SCOOTER 530 2016 TMAX XP500
1
1
2
3
4
5
6
7
8
9
10
11
12
1
PLUG CAP ASSY

59C823700000   59C823700000

59C823700000

Unit Price Incl. Tax

2
IGNITION COIL ASSY

59C823100000   59C823100000

59C823100000

Unit Price Incl. Tax

3
NUT, FLANGE(7NB)

957020650000  

957010650000
 957020650000

Unit Price Incl. Tax

4
BOLT, FLANGE

958020602000  

958010602000
 958020602000

Unit Price Incl. Tax

5
SENSOR, PRESSURE

1WS823800000   1WS823800000

1WS823800000

Unit Price Incl. Tax

6
BOLT, SOCKET

913120502000  

913170502000
 913120502000

Unit Price Incl. Tax

7
HORN

2PW833710000   2PW833710000

2PW833710000

Unit Price Incl. Tax

8
NUT, FLANGE

957020850000  

957010850000
 957020850000

Unit Price Incl. Tax

9
FLASHER RELAY ASSY

3GM833500100  

3GM833500100
Not available
10
SENSOR, AIR TEMPERATURE

5YU858860000   5YU858860000

5YU858860000

Unit Price Incl. Tax

11
BOLT, SOCKET

913120501200  

913170501200
 913120501200

Unit Price Incl. Tax

12
BUZZER

4D9833830000   4D9833830000

4D9833830000

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
