FRONT FORK FOR YAMAHA XP500A 2013

FUEL TANK

COVER

4PU2331G0000 4PU2331G0000

16,16 €

Unit Price Incl. Tax

UNDER BRACKET COMP.

4B5233401000 4B5233401000

578,04 €

Unit Price Incl. Tax

FRONT FORK ASSY (L.H)

4B5231020000 4B5231020000

766,30 €

Unit Price Incl. Tax

TUBE, OUTER (LEFT)

4B5231260000 4B5231260000

396,29 €

Unit Price Incl. Tax

INNER TUBE COMP.1

4B5231100000 4B5231100000

398,35 €

Unit Price Incl. Tax

PISTON, FRONT FORK

5EA231713000 5EA231713000

21,54 €

Unit Price Incl. Tax

CYLINDER COMP., FRONT FORK

4B5231700000 4B5231700000

394,69 €

Unit Price Incl. Tax

METAL, SLIDE 1

5EB231250000 5EB231250000

24,26 €

Unit Price Incl. Tax

WASHER

4V423146L000 4V423146L000

7,33 €

Unit Price Incl. Tax

OIL SEAL

4PU231450100 4PU231450100

19,18 €

Unit Price Incl. Tax

RING, SNAP

4V423153L000 4V423153L000

4,44 €

Unit Price Incl. Tax

SEAL, DUST

4PU231440000 4PU231440000

26,90 €

Unit Price Incl. Tax

SPINDLE, TAPER

4YR231730000 4YR231730000

37,65 €

Unit Price Incl. Tax

GASKET

50923158L000 50923158L000

2,72 €

Unit Price Incl. Tax

BOLT, HEXAGON SOCKET HEAD

278231815000

3D8231810000

11,12 €

Unit Price Incl. Tax

SPRING, FRONT FORK

4B5231410000 4B5231410000

99,99 €

Unit Price Incl. Tax

WASHER, SPRING UPPER

3LR231490000 3LR231490000

8,02 €

Unit Price Incl. Tax

SPACER

5WM231180000 5WM231180000

14,56 €

Unit Price Incl. Tax

BOLT, CAP

3TJ231110000 3TJ231110000

70,36 €

Unit Price Incl. Tax

O-RING

4V423188L000

Not available

FRONT FORK ASSY (R.H)

59C231030000 59C231030000

766,30 €

Unit Price Incl. Tax

NOT AVAILABLE

4B5231360000

Not available

INNER TUBE COMP.1

4B5231100000 4B5231100000

398,35 €

Unit Price Incl. Tax

PISTON, FRONT FORK

5EA231713000 5EA231713000

21,54 €

Unit Price Incl. Tax

CYLINDER COMP., FRONT FORK

4B5231700000 4B5231700000

394,69 €

Unit Price Incl. Tax

METAL, SLIDE 1

5EB231250000 5EB231250000

24,26 €

Unit Price Incl. Tax

WASHER

4V423146L000 4V423146L000

7,33 €

Unit Price Incl. Tax

OIL SEAL

4PU231450100 4PU231450100

19,18 €

Unit Price Incl. Tax

RING, SNAP

4V423153L000 4V423153L000

4,44 €

Unit Price Incl. Tax

SEAL, DUST

4PU231440000 4PU231440000

26,90 €

Unit Price Incl. Tax

SPINDLE, TAPER

4YR231730000 4YR231730000

37,65 €

Unit Price Incl. Tax

GASKET

50923158L000 50923158L000

2,72 €

Unit Price Incl. Tax

BOLT, HEXAGON SOCKET HEAD

278231815000

3D8231810000

11,12 €

Unit Price Incl. Tax

SPRING, FRONT FORK

4B5231410000 4B5231410000

99,99 €

Unit Price Incl. Tax

WASHER, SPRING UPPER

3LR231490000 3LR231490000

8,02 €

Unit Price Incl. Tax

SPACER

5WM231180000 5WM231180000

14,56 €

Unit Price Incl. Tax

BOLT, CAP

3TJ231110000 3TJ231110000

70,36 €

Unit Price Incl. Tax

O-RING

4V423188L000

Not available

BOLT, SOCKET

913120804000

913110804000

3,10 €

Unit Price Incl. Tax

BOLT, SOCKET

913120802500

913160802500

1,62 €

Unit Price Incl. Tax

BEARING

933999995700 933999995700

68,92 €

Unit Price Incl. Tax

SEAL, STEERING

3FV234620000 3FV234620000

17,59 €

Unit Price Incl. Tax

CAP, BOLT

59C234690000 59C234690000

7,81 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FRONT FORK of your Yamaha XP500A of 2013. Let us know if you have any questions.
