WATERPUMP / HOSES

RADIATOR / HOSES FOR YAMAHA XP500 2012

OIL PUMP

Item numbers

PIPE 3

59C124830000 59C124830000

13,80 €

Unit Price Incl. Tax

HOSE CLAMP ASSY

904503201500 904503201500

8,36 €

Unit Price Incl. Tax

CLIP

904672618900 904672618900

5,35 €

Unit Price Incl. Tax

THERMOSTAT ASSY

4JH124100000

4JH124100100

87,39 €

Unit Price Incl. Tax

COVER, THERMOSTAT

4B5124130000 4B5124130000

90,61 €

Unit Price Incl. Tax

BOLT, FLANGE

950220602500 950220602500

1,22 €

Unit Price Incl. Tax

PIPE 4

59C124840000 59C124840000

83,58 €

Unit Price Incl. Tax

BOLT, FLANGE

950220601200 950220601200

1,03 €

Unit Price Incl. Tax

RADIATOR COMP

59C124610000 59C124610000

679,59 €

Unit Price Incl. Tax

COCK, DRAIN

5VU124780000 5VU124780000

9,40 €

Unit Price Incl. Tax

BLOWER ASSY

59C124050000 59C124050000

407,17 €

Unit Price Incl. Tax

BOLT, BLOWER HOLDING

2S3126750000 2S3126750000

2,98 €

Unit Price Incl. Tax

NUT 1

5SL126710000 5SL126710000

3,54 €

Unit Price Incl. Tax

DAMPER, 4

59C284550000 59C284550000

10,74 €

Unit Price Incl. Tax

DAMPER 4

59C284350000 59C284350000

3,32 €

Unit Price Incl. Tax

GROMMET (5H0)

904801630100 904801630100

2,84 €

Unit Price Incl. Tax

COLLAR(51L)

90387065L700 90387065L700

4,44 €

Unit Price Incl. Tax

PIPE 5

59C124850000 59C124850000

8,02 €

Unit Price Incl. Tax

PIPE 6

59C124760000 59C124760000

52,59 €

Unit Price Incl. Tax

PIPE 7

59C124770000 59C124770000

32,07 €

Unit Price Incl. Tax

CAP, RADIATOR

5SL124620000 5SL124620000

44,99 €

Unit Price Incl. Tax

SUPT, FILLER NECK

5GJ125910000 5GJ125910000

84,03 €

Unit Price Incl. Tax

RIVET

902690700800 902690700800

2,08 €

Unit Price Incl. Tax

HOSE 1

59C1243A0000

59C1243A0100

21,03 €

Unit Price Incl. Tax

HOSE 2

4B51243E0000 4B51243E0000

32,95 €

Unit Price Incl. Tax

CLIP

904671500100 904671500100

3,10 €

Unit Price Incl. Tax

CLIP(4BH) 5PK

904671514100 904671514100

2,90 €

Unit Price Incl. Tax

CLIP

90467160A600 90467160A600

2,41 €

Unit Price Incl. Tax

CLIP

904671003800 904671003800

3,75 €

Unit Price Incl. Tax

CLIP (3G0)

904671003500

904671003900

2,98 €

Unit Price Incl. Tax

HOSE 6

59C125890000

59C125890100

18,81 €

Unit Price Incl. Tax

HOSE 7

59C125510000 59C125510000

42,23 €

Unit Price Incl. Tax

CLAMP(4HM)

904641319400 904641319400

3,87 €

Unit Price Incl. Tax

CLAMP

904642300100 904642300100

5,82 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
