STAND / FOOTREST FOR YAMAHA XP500 2015

STAND / FOOTREST 2

STAND, MAIN

2PW271110000 2PW271110000

230,70 €

Unit Price Incl. Tax

SPRING, TENSION

905064050800 905064050800

42,45 €

Unit Price Incl. Tax

SPRING, TENSION

905062350900 905062350900

11,98 €

Unit Price Incl. Tax

BOLT

901091002900 901091002900

12,03 €

Unit Price Incl. Tax

NUT, SELFLOCKING (533 FRAME)

901851002200

901851006000

5,60 €

Unit Price Incl. Tax

BRACKET, MAIN STAND

2PW271510000 2PW271510000

84,16 €

Unit Price Incl. Tax

STOPPER, MAIN STAND

36C271140000 36C271140000

10,57 €

Unit Price Incl. Tax

BOLT, FLANGE

901051028300 901051028300

4,61 €

Unit Price Incl. Tax

NUT, SELFLOCKING (533 FRAME)

901851002200

901851006000

5,60 €

Unit Price Incl. Tax

BRACKET, MAIN STAND 2

4B5271520000 4B5271520000

65,66 €

Unit Price Incl. Tax

BOLT, FLANGE

901051028300 901051028300

4,61 €

Unit Price Incl. Tax

NUT, SELFLOCKING (533 FRAME)

901851002200

901851006000

5,60 €

Unit Price Incl. Tax

BRACKET, SIDE STAND

2PW273210000 2PW273210000

98,26 €

Unit Price Incl. Tax

STAND, SIDE

2PW273110000 2PW273110000

88,82 €

Unit Price Incl. Tax

SPRING, TENSION

905062301400 905062301400

19,27 €

Unit Price Incl. Tax

STOPPER, MAIN STAND

4X4271140000

116271140000

6,04 €

Unit Price Incl. Tax

BOLT, BUTTON HEAD

920121004000 920121004000

3,79 €

Unit Price Incl. Tax

COLLAR

903871001800 903871001800

8,36 €

Unit Price Incl. Tax

958-69527-00 WASHER, PLAIN

929021020000

929901020000

2,08 €

Unit Price Incl. Tax

NUT U (707)

956021010000 956021010000

4,78 €

Unit Price Incl. Tax

REAR FOOTREST ASSY 1

2PW274300000 2PW274300000

185,95 €

Unit Price Incl. Tax

FOOTREST REAR 1

3VR274310100

3VR274310200

38,73 €

Unit Price Incl. Tax

PIN, COTTER (648)

914022001200

914012001500

2,68 €

Unit Price Incl. Tax

PIN, CLEVIS

917020603800 917020603800

2,12 €

Unit Price Incl. Tax

SPRING, COMPRESSION

905011500100 905011500100

2,48 €

Unit Price Incl. Tax

BALL 5PK

935010401100 935010401100

0,98 €

Unit Price Incl. Tax

COLLAR (24R)

90387064H800 90387064H800

4,78 €

Unit Price Incl. Tax

WASHER, SPECIAL

4B5274370000 4B5274370000

9,14 €

Unit Price Incl. Tax

HOLDER, BRAKE HOSE 2

59C258760000 59C258760000

11,56 €

Unit Price Incl. Tax

BOLT, FLANGE

958020601400

958210601400

1,44 €

Unit Price Incl. Tax

BOLT, FLANGE(4LN)

958120802500

958170802500

2,19 €

Unit Price Incl. Tax

REAR FOOTREST ASSY 2

2PW274400000 2PW274400000

185,95 €

Unit Price Incl. Tax

FOOTREST REAR 2

3VR274410100

3VR274410200

38,73 €

Unit Price Incl. Tax

PIN, COTTER (648)

914022001200

914012001500

2,68 €

Unit Price Incl. Tax

PIN, CLEVIS

917020603800 917020603800

2,12 €

Unit Price Incl. Tax

SPRING, COMPRESSION

905011500100 905011500100

2,48 €

Unit Price Incl. Tax

BALL 5PK

935010401100 935010401100

0,98 €

Unit Price Incl. Tax

COLLAR (24R)

90387064H800 90387064H800

4,78 €

Unit Price Incl. Tax

WASHER, SPECIAL

4B5274370000 4B5274370000

9,14 €

Unit Price Incl. Tax

BOLT, FLANGE(4LN)

958120802500

958170802500

2,19 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STAND / FOOTREST of your Yamaha XP500 of 2015. Let us know if you have any questions.
