SWINGARM / SHOCK ABSORBER FOR YAMAHA XP500 2011

STEERING

Item numbers

ARM, REAR 1

4B5221710133 4B5221710133

1 022,86 €

Unit Price Incl. Tax

BOLT

970020803500

970210803500

2,98 €

Unit Price Incl. Tax

WASHER, PLAIN (663) 5PK

929020860000

929900860000

1,14 €

Unit Price Incl. Tax

SHAFT, PIVOT

15B221410000 15B221410000

33,44 €

Unit Price Incl. Tax

WASHER, PLATE

902012201800 902012201800

6,30 €

Unit Price Incl. Tax

NUT, PIVOT SHAFT

1J7221430000 1J7221430000

12,03 €

Unit Price Incl. Tax

COVER

4KM2219X0000 4KM2219X0000

22,16 €

Unit Price Incl. Tax

BRG, CYL-CAL ROLLER 74G KY

933320001000 933320001000

53,89 €

Unit Price Incl. Tax

OIL SEAL (25X40X5-101)

931022501700 931022501700

7,33 €

Unit Price Incl. Tax

COLLAR

903871701100 903871701100

7,07 €

Unit Price Incl. Tax

PIN, DOWEL

995301401600 995301401600

4,78 €

Unit Price Incl. Tax

BOLT, FLANGE(4MY)

958121010000

958171010000

4,91 €

Unit Price Incl. Tax

BUMP, STOP

4B5224260000 4B5224260000

Not available

NUT, CROWN

901760601600 901760601600

5,35 €

Unit Price Incl. Tax

SHOCK ABSORBER ASSY, REAR

5VU222100000 5VU222100000

765,29 €

Unit Price Incl. Tax

LABEL, WARNING

4AA222594000 4AA222594000

12,32 €

Unit Price Incl. Tax

BOLT

901011600300 901011600300

14,07 €

Unit Price Incl. Tax

WASHER 1

4B5222430000 4B5222430000

4,00 €

Unit Price Incl. Tax

COLLAR

903871601900 903871601900

11,00 €

Unit Price Incl. Tax

BEARING, CYLINDRICAL(2GH)

933174176100 933174176100

55,88 €

Unit Price Incl. Tax

BOLT, FLANGE

901051205300 901051205300

11,64 €

Unit Price Incl. Tax

COLLAR

903871200300

903871205900

15,40 €

Unit Price Incl. Tax

COLLAR

903871203900 903871203900

19,52 €

Unit Price Incl. Tax

WASHER, PLATE

902011204300 902011204300

7,93 €

Unit Price Incl. Tax

NUT, SELF-LOCKING

956021220000 956021220000

2,52 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SWINGARM / SHOCK ABSORBER of your Yamaha XP500 of 2011. Let us know if you have any questions.
