FUEL TANK

SEAT FOR YAMAHA XP500S 2004

SEAT 2

NOT AVAILABLE

5GJ247303100

Not available

NOT AVAILABLE

5GJ247480000

Not available

SEAT COVER COMP.

5GJ2470F2000

5GJ2470F2100

124,12 €

Unit Price Incl. Tax

NOT AVAILABLE

5GJ2475M0000

Not available

NOT AVAILABLE

5GJ247410000

Not available

PLATE

5GJ247920000 5GJ247920000

12,84 €

Unit Price Incl. Tax

WASHER, PLATE

902010638000 902010638000

Not available

NUT, U FLANGE

956070620000

956020620000

2,08 €

Unit Price Incl. Tax

NOT AVAILABLE

5GJ247903000

Not available

NOT AVAILABLE

5GJ2477A3000

Not available

BOLT, FLANGE

958070602000

958170602000

1,82 €

Unit Price Incl. Tax

COVER, SEAT COMP.

5GJ2473F0000 5GJ2473F0000

21,49 €

Unit Price Incl. Tax

LID 1

5GJ2473T0000 5GJ2473T0000

21,54 €

Unit Price Incl. Tax

LEVER, SEAT

5GJ2477F0000 5GJ2477F0000

6,99 €

Unit Price Incl. Tax

HOOK, SEAT

5GJ247540000

5GJ247540100

7,24 €

Unit Price Incl. Tax

SPRING

4HC247580000 4HC247580000

7,93 €

Unit Price Incl. Tax

PIN, DOWEL(4HC)

936035019500 936035019500

5,35 €

Unit Price Incl. Tax

COVER

5GJ242170000 5GJ242170000

10,38 €

Unit Price Incl. Tax

SCREW, PAN TAP.2 SLIT

977070410800

977074060800

1,14 €

Unit Price Incl. Tax

5GJ247740000 5GJ247740000

6,30 €

Unit Price Incl. Tax

NOT AVAILABLE

5GJ247620000

Not available

RIVET(4JH)

902690707600 902690707600

2,08 €

Unit Price Incl. Tax

NOT AVAILABLE

5GJ2197J0000

Not available

BOLT(3KJ)

90109063F500 90109063F500

2,37 €

Unit Price Incl. Tax

WASHER, WAVE

902061003600 902061003600

6,72 €

Unit Price Incl. Tax

NUT(55X) 5PK

957070850000

901790849100

2,98 €

Unit Price Incl. Tax

STOPPER

5VU2478G0000 5VU2478G0000

134,02 €

Unit Price Incl. Tax

NOT AVAILABLE

5VU2474E0000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SEAT of your Yamaha XP500S of 2004. Let us know if you have any questions.
