CAMSHAFT / TIMING CHAIN

WATERPUMP / HOSES FOR YAMAHA XP500 2002

RADIATOR / HOSES

WATERPUMP / HOSES Yamaha SCOOTER 500 2002 TMAX XP500
1
WATER PUMP ASSY

5GJ124200000  

5GJ124200100
 5GJ124200000

Unit Price Incl. Tax

2
NOT AVAILABLE

5GJ124210000  

5GJ124210000
Not available
3
BRG, R-B 6001 28MM 28G KY

933060010600  

933060010500
 933060010600

Unit Price Incl. Tax

4
OIL SEAL(JA9)

931021244200   931021244200

931021244200

Unit Price Incl. Tax

5
SEAL, MECHANICAL

11H124381000   11H124381000

11H124381000

Unit Price Incl. Tax

6
NOT AVAILABLE

5GJ124500000  

5GJ124500000
Not available
7
COVER, HOUSING

5GJ124220000  

5GJ124220100
 5GJ124220000

Unit Price Incl. Tax

8
O-RING

1WG124390000   1WG124390000

1WG124390000

Unit Price Incl. Tax

9
BOLT, SOCKET

913170602000   913170602000

913170602000

Unit Price Incl. Tax

10
CIRCLIP(10Y)

990091240000   990091240000

990091240000

Unit Price Incl. Tax

11
O-RING (626)

932103313300   932103313300

932103313300

Unit Price Incl. Tax

12
BOLT, HEXAGON

970270603000  

970170603000
 970270603000

Unit Price Incl. Tax

13
WASHER(6TA) 10PK

929070660000   929070660000

929070660000

Unit Price Incl. Tax

14
PIPE 1

5GJ124810000  

15B124810000
 5GJ124810000

Unit Price Incl. Tax

15
PIPE 2

5GJ124820000  

5GJ124820100
 5GJ124820000

Unit Price Incl. Tax

16
O-RING 5PK

932102119000   932102119000

932102119000

Unit Price Incl. Tax

17
BOLT, HEXAGON

970270601600  

970170601600
 970270601600

Unit Price Incl. Tax

18
WASHER(6TA) 10PK

929070660000   929070660000

929070660000

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the WATERPUMP / HOSES of your Yamaha XP500 of 2002. Let us know if you have any questions.
