SWINGARM

STEERING FOR YAMAHA XT500 1986

FRONT FORK

RACE, BALL 1

156234110000

B6E234110000

20,61 €

Unit Price Incl. Tax

SEAL, DUST

164234620000 164234620000

10,38 €

Unit Price Incl. Tax

TE DE FOURCHE SUPERIEUR

H37234350000 H37234350000

Not available

NOT AVAILABLE

1E6234450000

Not available

SUPPORT, SUPERIEUR DE GUIDON

1R6234410000 1R6234410000

Not available

NOT AVAILABLE

1E6234420000

4AA234420198

BOLT, FLANGE

901050809100

958240804000

4,44 €

Unit Price Incl. Tax

NOT AVAILABLE

1T2233890000

Not available

WASHER, PLATE(47X)

902011219500

90201121J000

7,24 €

Unit Price Incl. Tax

RONDELLE, GROWER

902041074200 902041074200

Not available

RUBBER, BUSHING

1E6234340000 1E6234340000

4,08 €

Unit Price Incl. Tax

YBS67-10 WASHER, SPRING 5PK

929011010000

929901010000

2,12 €

Unit Price Incl. Tax

NUT(3BM)

953011070000

953031060000

2,41 €

Unit Price Incl. Tax

CLIP 136253750000

904681200600 904681200600

3,10 €

Unit Price Incl. Tax

BOLT, FLANGE

958210804000

901050809100

4,44 €

Unit Price Incl. Tax

BOLT, FLANGE

958210805500

958110805500

3,10 €

Unit Price Incl. Tax

NUT, FLANGE

957010810000

957010850000

2,19 €

Unit Price Incl. Tax

BOLT (2A2)

901051410200 901051410200

6,30 €

Unit Price Incl. Tax

NOT AVAILABLE

583234690000

Not available

NOT AVAILABLE

1E6233170000

Not available

RACE BALL

156234120000

B6E234120000

20,61 €

Unit Price Incl. Tax

BALL 5PK

935010401100 935010401100

0,98 €

Unit Price Incl. Tax

RACE, BALL 1

122234110000

22F234110000

10,57 €

Unit Price Incl. Tax

RACE, BALL 2

122234120000

22F234120000

19,14 €

Unit Price Incl. Tax

BALL

935031601000

935031600300

1,03 €

Unit Price Incl. Tax

NOT AVAILABLE

2Y0234160000

Not available

NUT

901792503300

901792500200

5,82 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STEERING of your Yamaha XT500 of 1986. Let us know if you have any questions.
