CYLINDER / CRANKCASE

CRANKSHAFT / PISTON FOR YAMAHA CY50R 1996

AIR SHROUD & FAN

CRANKSHAFT ASSY

3KJ114000000

3KJ114000100

189,99 €

Unit Price Incl. Tax

NOT AVAILABLE

3KJ114120000

Not available

PIN, CRANK 1

1YU116810000 1YU116810000

19,73 €

Unit Price Incl. Tax

BRG, NEEDLE

93310416N700 93310416N700

24,77 €

Unit Price Incl. Tax

ROD, CONNECTING

2E9116510000 2E9116510000

82,99 €

Unit Price Incl. Tax

NOT AVAILABLE

3KJ114220000

Not available

KEY WOODRUFF 146115450000

902800301700 902800301700

3,32 €

Unit Price Incl. Tax

BEARING(1GJ)

933062045800 933062045800

55,33 €

Unit Price Incl. Tax

OIL SEAL(1YU)

931022042500

931022037100

14,02 €

Unit Price Incl. Tax

OIL SEAL(1GJ)

931012013800 931012013800

13,01 €

Unit Price Incl. Tax

COLLAR(3FC)

90387156U000 90387156U000

13,87 €

Unit Price Incl. Tax

PISTON (STD)

3CP116310096 3CP116310096

111,78 €

Unit Price Incl. Tax

PISTON (0.25MM O/S)

3CP116350000 3CP116350000

110,22 €

Unit Price Incl. Tax

PISTON (0.50MM O/S)

3CP116360000

3CP116360900

110,22 €

Unit Price Incl. Tax

PIN, PISTON

27V116330000

3VLE16330000

11,41 €

Unit Price Incl. Tax

PISTON RING SET (STD)

260116010200 260116010200

35,63 €

Unit Price Incl. Tax

PISTON RING SET (1ST O/S)

260116011200

260116011300

54,69 €

Unit Price Incl. Tax

PISTON RING SET (2ND O/S)

260116012200 260116012200

54,69 €

Unit Price Incl. Tax

CIRCLIP(2JA)

934501112000 934501112000

1,03 €

Unit Price Incl. Tax

BEARING (27V)

93310210M000 93310210M000

22,20 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CRANKSHAFT / PISTON of your Yamaha CY50R of 1996. Let us know if you have any questions.
