INTAKE

CARBURETOR FOR YAMAHA TT-R50E 2011

EXHAUST

(1) 1P6-E4101-10

CARBURETOR ASSY 1

(2) 68V-8182L-00

O-RING 1

(3) 1P6-14147-00

O-RING

(4) 1P6-14142-12

JET, PILOT (# 12.5)

(5) 18A-1414A-63

JET, MAIN (# 62.5)

(6) 1P6-14141-12

NOZZLE, MAIN

(7) 1P6-1490J-00

NEEDLE SET

(8) 1P6-14185-00

FLOAT

(9) 1P6-14112-25

VALVE, THROTTLE 1

(10) 1P6-14131-00

SPRING, THROTTLE VALVE

(11) 98507-05008

SCREW, PAN HEAD(JN2)

(12) 5GJ-14945-00

PLATE

(13) 1P6-1410A-00

STARTER SET

(14) 1P6-14103-00

THROTTLE SCREW SET

(15) 1P6-14104-00

AIR SCREW SET

(16) 1P6-141A7-12

NEEDLE VALVE SET 2

(17) 98507-03006

SCREW, PAN

(18) 53L-14186-00

PIN, FLOAT

(19) 98507-04014

SCREW, PAN HEAD(N15)

(20) 92907-04100

WASHER(6TA)

(21) 1P6-14196-00

PIPE

(22) 5LW-14191-00

PLUG, DRAIN

(23) 1P6-14197-00

PIPE

(24) 1P6-14126-00

GASKET

(25) 5LW-14994-00

NET, FILTER

(26) 522-14161-00

NUT, CABLE ADJUSTING

(27) 5CY-14951-00

WASHER

(28) 5FU-83790-00

HEATER ASSY

(29) 5FU-82103-00

TERMINAL 1

(30) 3F9-14118-00

CAP

	Part number	Description	Qty
# 1	1P6-E4101-10 1P6E410110 1P6E410110	CARBURETOR ASSY 1	375,35 €
# 2	68V-8182L-00 68V8182L00 68V8182L00	O-RING 1	21,89 €
# 3	1P6-14147-00 1P61414700 1P61414700	O-RING	9,83 €
# 4	1P6-14142-12 1P61414212 1P61414212	JET, PILOT (# 12.5)	32,00 €
# 5	18A-1414A-63 18A1414A63 18A1414A63	JET, MAIN (# 62.5)	11,34 €
# 6	1P6-14141-12 1P61414112 1P61414112	NOZZLE, MAIN	52,31 €
# 7	1P6-1490J-00 1P61490J00 1P61490J00	NEEDLE SET	51,22 €
# 8	1P6-14185-00 1P61418500 1P61418500	FLOAT	30,87 €
# 9	1P6-14112-25 1P61411225 1P61411225	VALVE, THROTTLE 1	90,58 €
# 10	1P6-14131-00 1P61413100 1P61413100	SPRING, THROTTLE VALVE	11,06 €
# 11	98507-05008 9850705008 9850705008	SCREW, PAN HEAD(JN2)	0,60 €
# 12	5GJ-14945-00 5GJ1494500 5GJ1494500	PLATE	7,77 €
# 13	1P6-1410A-00 1P61410A00 1P61410A00	STARTER SET	71,52 €
# 14	1P6-14103-00 1P61410300 1P61410300	THROTTLE SCREW SET	84,45 €
# 15	1P6-14104-00 1P61410400 1P61410400	AIR SCREW SET	33,23 €
# 16	1P6-141A7-12 1P6141A712 1P6141A712	NEEDLE VALVE SET 2	100,49 €
# 17	98507-03006 9850703006 9850703006	SCREW, PAN	0,74 €
# 18	53L-14186-00 53L1418600 53L1418600	PIN, FLOAT	6,46 €
# 19	98507-04014 9850704014 9850704014	SCREW, PAN HEAD(N15)	0,60 €
# 20	92907-04100 9290704100 9290704100	WASHER(6TA)	0,27 €
# 21	1P6-14196-00 1P61419600 1P61419600	PIPE	6,76 €
# 22	5LW-14191-00 5LW1419100 5LW1419100	PLUG, DRAIN	4,11 €
# 23	1P6-14197-00 1P61419700 1P61419700	PIPE	21,76 €
# 24	1P6-14126-00 1P61412600 1P61412600	GASKET	9,09 €
# 25	5LW-14994-00 5LW1499400 5LW1499400	NET, FILTER	1,56 €
# 26	522-14161-00 5221416100 5221416100	NUT, CABLE ADJUSTING	5,67 €
# 27	5CY-14951-00 5CY1495100 5CY1495100	WASHER	3,43 €
# 28	5FU-83790-00 5FU8379000 5FU8379000	HEATER ASSY	52,36 €
# 29	5FU-82103-00 5FU8210300 5FU8210300	TERMINAL 1	3,62 €
# 30	3F9-14118-00 3F91411800 3F91411800	CAP	7,64 €

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CARBURETOR of your Yamaha TT-R50E of 2011. Let us know if you have any questions.
