Displacement

Year

Model

Finish line

Parts catalogue

Parts diagram

CYLINDER

CRANKSHAFT / PISTON FOR YAMAHA X-LIMIT 2002

WATERPUMP / HOSES

Item numbers
CRANKSHAFT / PISTON Yamaha MOTO 50 2002 MBK XLIMIT DT50 X-LIMIT
1
2
3
4
5
6
6
6
7
7
7
8
9
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
NOT AVAILABLE

4YVE14000000  

4YVE14000000
Not available
2
NOT AVAILABLE

1TKE14261000  

1TKE14261000
Not available
3
NOT AVAILABLE

1TKE14261000  

1TKE14261000
Not available
4
OIL SEAL(14Y)

908997117200  

931011780100
 908997117200

Unit Price Incl. Tax

5
OIL SEAL(14Y)

931012483500  

9310124X0000
 931012483500

Unit Price Incl. Tax

6
PISTON (STD)

4YVE16310000  

4YVE16310100
 4YVE16310000

Unit Price Incl. Tax

6
NOT AVAILABLE

4YVE16350000  

4YVE16350000
Not available
6
NOT AVAILABLE

4YVE16360000  

4YVE16360000
Not available
7
PISTON RING SET (0.25MM O/S)

4YVE16040000  

5WXE16040000
 4YVE16040000

Unit Price Incl. Tax

7
NOT AVAILABLE

4YVE16030000  

4YVE16030000
Not available
7
NOT AVAILABLE

4YVE16050000  

4YVE16050000
Not available
8
PIN, PISTON

4YVE16330000   4YVE16330000

4YVE16330000

Unit Price Incl. Tax

9
CIRCLIP

1TLE16340000   1TLE16340000

1TLE16340000

Unit Price Incl. Tax

10
ROLLER BEARING

1TLE12020000   1TLE12020000

1TLE12020000

Unit Price Incl. Tax

11
KEY WOODRUFF

1TLE15450000   1TLE15450000

1TLE15450000

Unit Price Incl. Tax

12
GEAR, BALANCE WEIG

4YVE15360000  

1D4E15310000
 4YVE15360000

Unit Price Incl. Tax

13
WEIGHT 1

4YVE14540000  

4YVE14541000
 4YVE14540000

Unit Price Incl. Tax

14
NOT AVAILABLE

93306202X200  

93306202X200
Not available
15
BEARING

93306203X600   93306203X600

93306203X600

Unit Price Incl. Tax

16
GEAR, BALANCE WEIG

4YVE15310000  

1D4E15310000
 4YVE15310000

Unit Price Incl. Tax

17
CHAVETA RECTA

902820480700   902820480700

902820480700

Unit Price Incl. Tax

18
WASHER, SPECIAL

1TKE74170000   1TKE74170000

1TKE74170000

Unit Price Incl. Tax

19
TUERCA

901701285300   901701285300

901701285300

Unit Price Incl. Tax

20
CHAVETA RECTA

902820480600   902820480600

902820480600

Unit Price Incl. Tax

21
COLLAR

90387168P100  

9038716X0200
 90387168P100

Unit Price Incl. Tax

22
O-RING

3UDE56630000   3UDE56630000

3UDE56630000

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CRANKSHAFT / PISTON of your Yamaha X-LIMIT of 2002. Let us know if you have any questions.
