FRONT SUSPENSION / WHEEL

STEERING FOR YAMAHA KODIAK 450 2024

FUEL TANK

Item numbers

BRACKET, STEERING

1CUF131H0000 1CUF131H0000

55,36 €

Unit Price Incl. Tax

BOLT, FLANGE

901050823700 901050823700

4,00 €

Unit Price Incl. Tax

BEARING

93306203YN00 93306203YN00

23,92 €

Unit Price Incl. Tax

OIL SEAL (25X44X6-810)

931022508100 931022508100

7,42 €

Unit Price Incl. Tax

OIL SEAL (25X36X8-334)

931022509900 931022509900

10,21 €

Unit Price Incl. Tax

HOLDER, BEARING

2GU238720000 2GU238720000

27,75 €

Unit Price Incl. Tax

COLUMN STEERING 2

BJ5F38130000 BJ5F38130000

247,49 €

Unit Price Incl. Tax

ARM PITMAN

BJ5F38160100 BJ5F38160100

69,84 €

Unit Price Incl. Tax

HOLDER, HANDLE UPPER

8K1238140000

1E6234410000

32,67 €

Unit Price Incl. Tax

BOLT, FLANGE DEEP

95D320803000 95D320803000

1,73 €

Unit Price Incl. Tax

PLANE BEARING, STE

1CTF38120000 1CTF38120000

8,02 €

Unit Price Incl. Tax

WASHER, LOCK 1

1CTF38940000 1CTF38940000

1,44 €

Unit Price Incl. Tax

BRACKET, STEERING

1CTF253F0000 1CTF253F0000

23,17 €

Unit Price Incl. Tax

WASHER, PLATE

902010805500 902010805500

1,22 €

Unit Price Incl. Tax

NUT(4KM)

901790867400 901790867400

3,10 €

Unit Price Incl. Tax

BOLT, FLANGE

958120802000 958120802000

1,40 €

Unit Price Incl. Tax

BRACKET, STEERING

1CTF38680000 1CTF38680000

11,77 €

Unit Price Incl. Tax

BRACKET, STEERING

1CTF19570000 1CTF19570000

7,42 €

Unit Price Incl. Tax

NOT AVAILABLE

970120808000

Not available

COLLAR, 2

1CTF15450100 1CTF15450100

Not available

WASHER, PLATE

902011402100 902011402100

6,85 €

Unit Price Incl. Tax

NUT, SELF-LOCKING

901851400900 901851400900

10,74 €

Unit Price Incl. Tax

PIN, COTTER

914022002500

914012003000

4,70 €

Unit Price Incl. Tax

ROD TIE

BB5238310000 BB5238310000

28,43 €

Unit Price Incl. Tax

JOINT, UNIVERSAL 1

1UY238410100 1UY238410100

68,34 €

Unit Price Incl. Tax

JOINT, UNIVERSAL 2

1UY238450100 1UY238450100

68,97 €

Unit Price Incl. Tax

NUT(3BM)

953021070000

953031060000

2,41 €

Unit Price Incl. Tax

NUT

901701001000 901701001000

2,19 €

Unit Price Incl. Tax

WASHER (25G)

902091022900 902091022900

2,19 €

Unit Price Incl. Tax

NUT, CASTLE

901711000100 901711000100

3,67 €

Unit Price Incl. Tax

PIN, COTTER 5PK

914022502000

914902502000

2,00 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STEERING of your Yamaha KODIAK 450 of 2024. Let us know if you have any questions.
