SWINGARM

REAR SHOCK ABSORBER FOR YAMAHA YZ450F 2011

STEERING

(1) 33D-22200-50

SHOCK ABSORBER ASSY, REAR

(2) 33D-22201-10

DAMPER SUB ASSY

(2) 33D-22201-10

DAMPER SUB ASSY

(2) 33D-22201-10

DAMPER SUB ASSY

(3) 509-23184-L0

CAP, AIR VALVE

(4) 4JX-22226-00

BUSH, SHOCK ABSORBER LOWER

(5) 5DH-23183-00

CIRCLIP

(6) 33D-22234-00

GUIDE, SPRING 3

(7) 33D-22213-00

SEAT, SPRING UPPER

(8) 4AA-22259-40

LABEL, WARNING

(8) 4AA-22259-40

LABEL, WARNING

(8) 4AA-22259-40

LABEL, WARNING

(9) 33D-22212-30

SPRING

(9) 33D-22212-D0

SPRING

(10) 33D-22214-00

GUIDE, SPRING 1

(11) 33D-22224-00

GUIDE, SPRING 2

(12) 1C3-22253-50

COLLAR, DISTANCE

(12) 1C3-22253-50

COLLAR, DISTANCE

(13) 3JE-22475-00

SEAL, DUST

(13) 3JE-22475-00

SEAL, DUST

(14) 4EW-22474-00

SEAL, RING

(14) 4EW-22474-00

SEAL, RING

(15) 5UN-22176-00

BEARING

(16) 5MV-22184-00

BUSH

(17) 17D-22253-00

COLLAR, DISTANCE

(17) 17D-22253-00

COLLAR, DISTANCE

(18) 5NY-22475-00

SEAL, DUST

(18) 5NY-22475-00

SEAL, DUST

(19) 5XE222420100

BOLT 2

(20) 95602-10200

NUT, U FLANGE

(21) 929071020000

WASHER, PLAIN(3BM)

(22) 5NY-22241-00

BOLT 1

(23) 90185-10012

NUT, SELF-LOCKING

	Part number	Description	Qty
# 1	33D-22200-50 33D2220050 33D2220050	SHOCK ABSORBER ASSY, REAR	1 186,97 €
# 2	33D-22201-10 33D2220110 33D2220110	DAMPER SUB ASSY	3 233,78 €
# 3	509-23184-L0 50923184L0 50923184L0	CAP, AIR VALVE	9,37 €
# 4	4JX-22226-00 4JX2222600 4JX2222600	BUSH, SHOCK ABSORBER LOWER	59,40 €
# 5	5DH-23183-00 5DH2318300 5DH2318300	CIRCLIP	2,52 €
# 6	33D-22234-00 33D2223400 33D2223400	GUIDE, SPRING 3	42,24 €
# 7	33D-22213-00 33D2221300 33D2221300	SEAT, SPRING UPPER	63,01 €
# 8	4AA-22259-40 4AA2225940 4AA2225940	LABEL, WARNING	11,44 €
# 9	33D-22212-30 33D2221230 33D2221230	SPRING	552,38 €
# 9	33D-22212-D0 33D22212D0 33D22212D0	SPRING	552,38 €
# 10	33D-22214-00 33D2221400 33D2221400	GUIDE, SPRING 1	59,95 €
# 11	33D-22224-00 33D2222400 33D2222400	GUIDE, SPRING 2	14,54 €
# 12	1C3-22253-50 1C32225350 1C32225350	COLLAR, DISTANCE	20,61 €
# 13	3JE-22475-00 3JE2247500 3JE2247500	SEAL, DUST	3,25 €
# 14	4EW-22474-00 4EW2247400 4EW2247400	SEAL, RING	3,62 €
# 15	5UN-22176-00 5UN2217600 5UN2217600	BEARING	37,39 €
# 16	5MV-22184-00 5MV2218400 5MV2218400	BUSH	27,21 €
# 17	17D-22253-00 17D2225300 17D2225300	COLLAR, DISTANCE	59,86 €
# 18	5NY-22475-00 5NY2247500 5NY2247500	SEAL, DUST	13,58 €
# 19	5XE-22242-00 5XE222420100 5XE2224200	BOLT 2	8,13 €
# 20	95602-10200 9560210200 9560210200	NUT, U FLANGE	4,24 €
# 21	92902-10200 929071020000 9290210200	WASHER, PLAIN(3BM)	1,09 €
# 22	5NY-22241-00 5NY2224100 5NY2224100	BOLT 1	6,76 €
# 23	90185-10012 9018510012 9018510012	NUT, SELF-LOCKING	3,62 €

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the REAR SHOCK ABSORBER of your Yamaha YZ450F of 2011. Let us know if you have any questions.
