Displacement

Year

Model

Finish line

Parts catalogue

Parts diagram

FUEL TANK

GENERATOR FOR YAMAHA F40F ELECTRIC STARTER, TILLER HANDLE, HYDRO TRIM & TILT, SHAFT 15" 2011

ELECTRICAL 1

Item numbers
GENERATOR Yamaha OUTBOARD ENGINES 40hp (29.4kW) 2011 F40 F40FEHDS
1
2
3
4
5
6
7
8
9
10
11
12
13
13
13
13
14
15
16
17
18
19
20
21
22
1
ROTOR ASSY

6BG814500000   6BG814500000

6BG814500000

Unit Price Incl. Tax

2
STATOR ASSY

6BG814100000   6BG814100000

6BG814100000

Unit Price Incl. Tax

3
KEY, WOODRUFF

6H4115450000   6H4115450000

6H4115450000

Unit Price Incl. Tax

4
NUT, HEXAGON(663)

901702013700   901702013700

901702013700

Unit Price Incl. Tax

5
WASHER, PLATE (663)

9020121M1800   9020121M1800

9020121M1800

Unit Price Incl. Tax

6
BOLT, FLANGE(4AS)

950230603000  

950240603000
 950230603000

Unit Price Incl. Tax

7
BASE, MAGNETO

6BG855610094  

6BG855610000
 6BG855610094

Unit Price Incl. Tax

8
BOLT, FLANGE(4AS)

950230603000  

950240603000
 950230603000

Unit Price Incl. Tax

9
COIL, PULSER

6AH855800000   6AH855800000

6AH855800000

Unit Price Incl. Tax

10
BOLT(6A1)

970950501600   970950501600

970950501600

Unit Price Incl. Tax

11
WASHER, PLAIN (646)

929950560000  

929900560000
 929950560000

Unit Price Incl. Tax

12
COVER, FLYWHEEL WITH PLUG

6BG813370000  

6BG813370900
 6BG813370000

Unit Price Incl. Tax

13
GROMMET(3AA)

904801231400  

904801249700
 904801231400

Unit Price Incl. Tax

14
PULLER, FUSE

67F2812A0000   67F2812A0000

67F2812A0000

Unit Price Incl. Tax

15
DAMPER, FORM

6BG426170000   6BG426170000

6BG426170000

Unit Price Incl. Tax

16
MARK, CAUTION

6BG134376000  

6BG134376100
 6BG134376000

Unit Price Incl. Tax

17
LABEL, WARNING

6AH819954000  

6EEH19954000
 6AH819954000

Unit Price Incl. Tax

18
LABEL, WARNING

6AH819955000  

6EEH19955000
 6AH819955000

Unit Price Incl. Tax

19
LABEL, SAFETY

6AH819944000  

6EEH19944000
 6AH819944000

Unit Price Incl. Tax

20
LABEL, SAFETY

6AH819945000  

6EEH19945000
 6AH819945000

Unit Price Incl. Tax

21
GRAPHIC, REGULATOR

6BG819190000   6BG819190000

6BG819190000

Unit Price Incl. Tax

22
NOT AVAILABLE

6C5823770000  

6C5823770000
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the GENERATOR of your Yamaha F40F Electric Starter, Tiller Handle, Hydro Trim & Tilt, Shaft 15" of 2011. Let us know if you have any questions.
