STARTER MOTOR

STARTER CLUTCH FOR YAMAHA XMAX 400 2013

TRANSMISSION

PRIMARY SHEAVE CAP COMP.

1SDW17620000

1SDWE7620000

298,52 €

Unit Price Incl. Tax

OIL SEAL

931013580000 931013580000

7,66 €

Unit Price Incl. Tax

WEIGHT

1SDE76320100 1SDE76320100

9,70 €

Unit Price Incl. Tax

NOT AVAILABLE

1SDE76230000

Not available

SLIDER

1SDE76530000 1SDE76530000

5,73 €

Unit Price Incl. Tax

NOT AVAILABLE

1SDE76850000

Not available

O-RING

9321027X0000

9321027ME300

2,41 €

Unit Price Incl. Tax

V-BELT

1SDE76410000 1SDE76410000

223,48 €

Unit Price Incl. Tax

SHEAVE, PRIMARY FIXED

1SDE76110000

34B176110000

116,70 €

Unit Price Incl. Tax

SECONDARY FIXED SHEAVE COMP.

1SDE76600000

1SDE76601000

457,12 €

Unit Price Incl. Tax

SECONDARY SLIDING SHEAVE

1SDE76700000 1SDE76700000

142,47 €

Unit Price Incl. Tax

OIL SEAL

1B9E76F30000

931044111900

12,93 €

Unit Price Incl. Tax

NOT AVAILABLE

9321043X0200

Not available

PIN, GUIDE

1SDE76640000

1SDE76641000

14,35 €

Unit Price Incl. Tax

SPRING, COMPRESSION

9050155X0000 9050155X0000

67,54 €

Unit Price Incl. Tax

SPRING SEAT COMP.

5RU176900000 5RU176900000

58,06 €

Unit Price Incl. Tax

CLUTCH CARRIER ASSY

34B166200000 34B166200000

199,26 €

Unit Price Incl. Tax

PLATE, WEIGHT THRUST

34B165230000 34B165230000

15,07 €

Unit Price Incl. Tax

SPRING, CLUTCH WEIGHT 1

34B166260000

34B166260100

14,82 €

Unit Price Incl. Tax

CIRCLIP(2R6)

990010860000 990010860000

2,00 €

Unit Price Incl. Tax

NUT (5G3)

9017036X0300

901703627900

15,49 €

Unit Price Incl. Tax

CLUTCH HOUSING COMP.

34B166110000 34B166110000

232,33 €

Unit Price Incl. Tax

WASHER, PLATE

9020117X0300

90201173U500

7,33 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha XMAX 400 of 2013. Let us know if you have any questions.
