CYLINDER

CRANKSHAFT / PISTON FOR YAMAHA YFM350U 1998

VALVE

Item numbers

NOT AVAILABLE

1YW114000200

Not available

CRANK SUB ASSY 1

1UYW11410000

1UY114010900

476,64 €

Unit Price Incl. Tax

NOT AVAILABLE

1YW114220200

Not available

PIN, CRANK 1

30X116810000 30X116810000

87,15 €

Unit Price Incl. Tax

BEARING, CYLINDRICAL(2JN)

93310633T500 93310633T500

67,99 €

Unit Price Incl. Tax

ROD, CONNECTING

1UY116510000 1UY116510000

136,47 €

Unit Price Incl. Tax

WASHER (30X)

902093325300 902093325300

10,05 €

Unit Price Incl. Tax

NOT AVAILABLE

90387291R600

Not available

CIRCLIP

990092840000 990092840000

3,10 €

Unit Price Incl. Tax

BEARING(3KW)

933063062200

933063063000

105,12 €

Unit Price Incl. Tax

NOT AVAILABLE

1YW114960000

Not available

WASHER, PLATE (21V)

90201406F400 90201406F400

20,32 €

Unit Price Incl. Tax

SPRING, COMPRESSION (5Y1)

905012272100 905012272100

4,49 €

Unit Price Incl. Tax

PIN, DOWEL 5PK

936051009000 936051009000

3,67 €

Unit Price Incl. Tax

GEAR, BALANCE WT

3Y1115310100

3Y1115310200

112,41 €

Unit Price Incl. Tax

NOT AVAILABLE

1YW115650000

Not available

KEY, WOODRUFF

902800501300

902801605300

11,98 €

Unit Price Incl. Tax

BOLT (21V)

901011056800 901011056800

3,87 €

Unit Price Incl. Tax

WASHER(6TA)

929071010000 929071010000

1,11 €

Unit Price Incl. Tax

O-RING (538)

932101629000 932101629000

5,73 €

Unit Price Incl. Tax

WASHER, PLATE

90201107F800

902011005800

7,66 €

Unit Price Incl. Tax

KEY, WOODRUFF

902800504800

902800501300

11,98 €

Unit Price Incl. Tax

NOT AVAILABLE

1YW1163101Y0

Not available

PISTON RING SET (STD)

4GB116100000 4GB116100000

90,68 €

Unit Price Incl. Tax

PISTON RING SET (0.50MM O/S)

4GB116102000 4GB116102000

90,68 €

Unit Price Incl. Tax

PISTON RING SET (1.00MM O/S)

4GB116104000 4GB116104000

90,68 €

Unit Price Incl. Tax

PIN, PISTON

55V116330000 55V116330000

44,66 €

Unit Price Incl. Tax

CIRCLIP (26H) 5PK

934501909500 934501909500

1,03 €

Unit Price Incl. Tax

GEAR, DRIVE

1UY115360000

1UY115360100

153,80 €

Unit Price Incl. Tax

NOT AVAILABLE

1YW114540000

Not available

OIL SEAL (5Y1)

931012510600 931012510600

8,11 €

Unit Price Incl. Tax

BEARING

933062053200 933062053200

52,68 €

Unit Price Incl. Tax

NOT AVAILABLE

90387201R700

Not available

KEY, STRAIGHT (3L5)

902820503400 902820503400

2,19 €

Unit Price Incl. Tax

NUT, HEXAGON (30X)

901701632600 901701632600

9,96 €

Unit Price Incl. Tax

WASHER, LOCK(2NL)

902151627000 902151627000

11,48 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CRANKSHAFT / PISTON of your Yamaha YFM350U of 1998. Let us know if you have any questions.
