SWITCH / LEVER

ELECTRICAL 1 FOR YAMAHA YZF-R3A 2015

ELECTRICAL 2

IGNITION COIL ASSY

1WDH23100000

1WDH23100100

80,10 €

Unit Price Incl. Tax

COVER IGNITION CO

1WDH23140000 1WDH23140000

2,48 €

Unit Price Incl. Tax

COVER IGNITION CO

1WDH23141000 1WDH23141000

2,48 €

Unit Price Incl. Tax

BOLT, FLANGE

950220602000 950220602000

1,11 €

Unit Price Incl. Tax

PLUG CAP ASSY

1WDH23700000 1WDH23700000

47,51 €

Unit Price Incl. Tax

BATTERY ASSY (GS G

1WDH21000000

Not available

PAD BATTERY

1WDH21210000 1WDH21210000

7,24 €

Unit Price Incl. Tax

BAND BATTERY

1WDH21310000 1WDH21310000

4,00 €

Unit Price Incl. Tax

WIRE HARNESS ASSY

B02H25900000 B02H25900000

604,24 €

Unit Price Incl. Tax

FUSE (7.5A BL)

1WDH21512000 1WDH21512000

4,56 €

Unit Price Incl. Tax

FUSE (15A-BL)

1WDH21511000 1WDH21511000

4,56 €

Unit Price Incl. Tax

DIODE ASSY

4WA819800000 4WA819800000

24,38 €

Unit Price Incl. Tax

DIODE ASSY

3WP819800000 3WP819800000

17,47 €

Unit Price Incl. Tax

FUSE

1WDH21513000 1WDH21513000

4,56 €

Unit Price Incl. Tax

RELAY ASSY

1WDH19500000 1WDH19500000

35,01 €

Unit Price Incl. Tax

STARTER RELAY ASSY

1WDH19400000 1WDH19400000

71,44 €

Unit Price Incl. Tax

FUSE (30A-BL)

1WDH21510000 1WDH21510000

4,56 €

Unit Price Incl. Tax

BOLT

913120500800 913120500800

1,22 €

Unit Price Incl. Tax

WIRE PLUS LEAD

2WDH21150000 2WDH21150000

29,00 €

Unit Price Incl. Tax

WIRE MINUS LEAD

2WDH21160000 2WDH21160000

29,00 €

Unit Price Incl. Tax

CLAMP

904643680000 904643680000

1,14 €

Unit Price Incl. Tax

CLAMP

904647080000 904647080000

0,80 €

Unit Price Incl. Tax

CLAMP

904641480300 904641480300

1,82 €

Unit Price Incl. Tax

CLAMP

904642280000 904642280000

0,84 €

Unit Price Incl. Tax

MAIN SWITCH STEERI

1WDH25010100

1WDH25010200

152,88 €

Unit Price Incl. Tax

BOLT

90109060G400

901090628200

6,04 €

Unit Price Incl. Tax

MAIN SW. STRG. LOC

1WDXH2500000

1WDXH2500100

219,33 €

Unit Price Incl. Tax

SWITCH, SIDE STAND

1WDH25660000

1WDH25660100

60,06 €

Unit Price Incl. Tax

BAND

1WDF179E0000 1WDF179E0000

6,09 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 1 of your Yamaha YZF-R3A of 2015. Let us know if you have any questions.
