STARTER MOTOR

STARTER CLUTCH FOR YAMAHA XMAX 250 2016

TRANSMISSION

CLUTCH HOUSING COMP.

5GM166110000 5GM166110000

145,10 €

Unit Price Incl. Tax

NUT(22F)

901791446900 901791446900

15,40 €

Unit Price Incl. Tax

PIMARY SLIDING SHAVE COMP

1C0E76061000 1C0E76061000

227,05 €

Unit Price Incl. Tax

OIL SEAL(14Y)

931012880000 931012880000

9,18 €

Unit Price Incl. Tax

CAM

1C0E76231000 1C0E76231000

74,01 €

Unit Price Incl. Tax

SLIDER 10PK

1C0E76531000 1C0E76531000

2,84 €

Unit Price Incl. Tax

WEIGHT

1C0E76322100 1C0E76322100

6,63 €

Unit Price Incl. Tax

O-RING

9321117X0100 9321117X0100

4,78 €

Unit Price Incl. Tax

NOT AVAILABLE

1C0E76391000

999999999900

BOLT, HEXAGON SOCKET HEAD(M01)

9011004X0000 9011004X0000

1,82 €

Unit Price Incl. Tax

SPACER 1

1C0E76541000 1C0E76541000

3,10 €

Unit Price Incl. Tax

NOT AVAILABLE

9038719X0000

Not available

WASHER, PLATE

9020104X0500

902010480200

2,48 €

Unit Price Incl. Tax

NOT AVAILABLE

9020114X0200

Not available

V-BELT

5SEE76410200 5SEE76410200

103,39 €

Unit Price Incl. Tax

NOT AVAILABLE

1C0E76111000

Not available

NUT(22F)

901791446900 901791446900

15,40 €

Unit Price Incl. Tax

SECONDARY FIXED SHEAVE COMP.

37PE76601000 37PE76601000

215,75 €

Unit Price Incl. Tax

SECONDARY SLIDING SHEAVE

37PE76701000 37PE76701000

115,47 €

Unit Price Incl. Tax

OIL SEAL

931044111900 931044111900

12,93 €

Unit Price Incl. Tax

NOT AVAILABLE

9321043X0300

Not available

PIN, GUIDE

1SDE76641000 1SDE76641000

14,35 €

Unit Price Incl. Tax

SPRING (278-13169-00)

9050150X0200 9050150X0200

38,20 €

Unit Price Incl. Tax

SEAT, SPRING

5GM176440000 5GM176440000

58,81 €

Unit Price Incl. Tax

CLUTCH CARRIER ASSY

5GM166200100 5GM166200100

273,26 €

Unit Price Incl. Tax

SPRING, CLUTCH WEIGHT 1

5KD166261000

5KD166261100

13,49 €

Unit Price Incl. Tax

CIRCLIP(2R6)

990010860000 990010860000

2,00 €

Unit Price Incl. Tax

NOT AVAILABLE

9017036X0400

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
