STARTER CLUTCH

STARTER CLUTCH FOR YAMAHA YFM250R 2009

TRANSMISSION

Item numbers

GEAR, PRIMARY DRIVE

4D3161110000 4D3161110000

121,14 €

Unit Price Incl. Tax

KEY, STRAIGHT(3UR)

902820507700 902820507700

4,78 €

Unit Price Incl. Tax

WASHER, CLAW(4GY)

902141606300 902141606300

1,62 €

Unit Price Incl. Tax

WASHER, LOCK

902151629300 902151629300

10,57 €

Unit Price Incl. Tax

NUT

901701600300 901701600300

2,98 €

Unit Price Incl. Tax

PRIMARY DRIVEN GEAR COMP.

4D3161500000 4D3161500000

495,69 €

Unit Price Incl. Tax

PLATE, THRUST 1

30X161540000 30X161540000

14,05 €

Unit Price Incl. Tax

BOSS, CLUTCH

4D3163710000 4D3163710000

203,38 €

Unit Price Incl. Tax

PLATE, FRICTION

3XJ163210000 3XJ163210000

21,40 €

Unit Price Incl. Tax

PLATE, FRICTION

5DH163210000 5DH163210000

21,16 €

Unit Price Incl. Tax

PLATE, CLUTCH 1

3XJ163240100

Not available

PLATE, PRESSURE 1

4GY163510000 4GY163510000

94,82 €

Unit Price Incl. Tax

PLATE, PUSH

1W1163580100 1W1163580100

13,94 €

Unit Price Incl. Tax

ROD, PUSH 1

5XT163560000 5XT163560000

19,73 €

Unit Price Incl. Tax

YBS66-6 WASHER, PLAIN 5PK

929020620000

929900620000

1,14 €

Unit Price Incl. Tax

NUT(661)

953020660000

953030660000

3,10 €

Unit Price Incl. Tax

SPRING, COMPRESSION(1UY)

90501231E900 90501231E900

11,33 €

Unit Price Incl. Tax

SCREW, WITH WASHER

901590602900 901590602900

1,40 €

Unit Price Incl. Tax

WASHER, LOCK(4KB)

902151628900 902151628900

Not available

NUT, HEXAGON (30X)

901701632600 901701632600

9,96 €

Unit Price Incl. Tax

PUSH LEVER COMP.

4D3163810000 4D3163810000

134,75 €

Unit Price Incl. Tax

BOLT

901090810500 901090810500

2,41 €

Unit Price Incl. Tax

WASHER, PLATE 3411117500

904300811900

902010808700

3,32 €

Unit Price Incl. Tax

SPRING, TORSION

90508203B300 90508203B300

6,04 €

Unit Price Incl. Tax

CIRCLIP(1EV)

990092050000 990092050000

1,14 €

Unit Price Incl. Tax

OIL SEAL (4G0)

931021222400 931021222400

15,28 €

Unit Price Incl. Tax

BEARING

933171128700 933171128700

15,45 €

Unit Price Incl. Tax

ROD, PUSH 2

4GY163570000 4GY163570000

65,74 €

Unit Price Incl. Tax

BALL (498) 5PK

935113201700

935113202700

3,32 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
