CAMSHAFT / TIMING CHAIN

OIL PUMP FOR YAMAHA YFM250R 2009

OIL COOLER

Item numbers
OIL PUMP Yamaha QUAD 250 2009 RAPTOR YFM250R
1
2
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
17
18
19
19
1
OIL PUMP ASSY

4D3133000000   4D3133000000

4D3133000000

Unit Price Incl. Tax

2
GEAR, PUMP DRIVEN 2

4D3133260000   4D3133260000

4D3133260000

Unit Price Incl. Tax

3
CIRCLIP(24H)

990091140000   990091140000

990091140000

Unit Price Incl. Tax

4
GASKET, PUMP COVER

4D3133290000   4D3133290000

4D3133290000

Unit Price Incl. Tax

5
SCREW

901490609300  

901490612200
 901490609300

Unit Price Incl. Tax

6
GASKET (3Y1)

904300615600   904300615600

904300615600

Unit Price Incl. Tax

7
STRAINER, OIL

22F134110100   22F134110100

22F134110100

Unit Price Incl. Tax

8
ELEMENT ASSY, OIL CLEANER

5D3134400000  

5D3134400100
 5D3134400000

Unit Price Incl. Tax

9
COVER, OIL ELEMENT

4D3134470000   4D3134470000

4D3134470000

Unit Price Incl. Tax

10
O-RING (341)

932105417500   932105417500

932105417500

Unit Price Incl. Tax

11
BOLT

901090616900   901090616900

901090616900

Unit Price Incl. Tax

12
O-RING (583 OIL DRAIN 5PK

932100713500   932100713500

932100713500

Unit Price Incl. Tax

13
BOLT

913120607000   913120607000

913120607000

Unit Price Incl. Tax

14
BOLT

913120602000   913120602000

913120602000

Unit Price Incl. Tax

15
PIPE, DELIVERY 1

5XT131610000  

5XT131610100
 5XT131610000

Unit Price Incl. Tax

16
BOLT, UNION (716)

904011006100   904011006100

904011006100

Unit Price Incl. Tax

17
GASKET (5R6) 5PK

904301017100   904301017100

904301017100

Unit Price Incl. Tax

18
BOLT, UNION

904010800900  

904010801200
 904010800900

Unit Price Incl. Tax

19
WASHER, PLATE 3411117500

904300811900  

902010808700
 904300811900

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
