ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA YZ250FX 2015

OPTIONAL PARTS

RECTIFIER & REGULATOR ASSY

2GB819600000 2GB819600000

157,00 €

Unit Price Incl. Tax

BRACKET, REGULATOR

1SL212870000 1SL212870000

24,43 €

Unit Price Incl. Tax

BOLT, FLANGE

901050620300 901050620300

2,12 €

Unit Price Incl. Tax

GROMMET

904801302500 904801302500

4,44 €

Unit Price Incl. Tax

COLLAR (8H6)

90387066J900

903870757300

2,12 €

Unit Price Incl. Tax

BOLT, FLANGE

901050606400 901050606400

1,29 €

Unit Price Incl. Tax

WIRE HARNESS ASSY

B29825900000 B29825900000

732,47 €

Unit Price Incl. Tax

DIODE ASSY

3WP819800000 3WP819800000

17,47 €

Unit Price Incl. Tax

DIODE ASSY

4WA819800000 4WA819800000

24,38 €

Unit Price Incl. Tax

FUSE (5A)

5JJ821519000

67F821512000

11,05 €

Unit Price Incl. Tax

WIRE, SUB LEAD

1SL823090000 1SL823090000

29,75 €

Unit Price Incl. Tax

CONNECTOR

33D823780000 33D823780000

13,41 €

Unit Price Incl. Tax

PLATE

1SL823880000 1SL823880000

6,77 €

Unit Price Incl. Tax

BOLT, FLANGE

901050611000 901050611000

1,11 €

Unit Price Incl. Tax

PLATE 2

1SL823890000 1SL823890000

8,49 €

Unit Price Incl. Tax

BOLT, SOCKET

913800601200 913800601200

2,90 €

Unit Price Incl. Tax

CLAMP

904641700300 904641700300

2,79 €

Unit Price Incl. Tax

CLAMP

904651009800 904651009800

1,40 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307300

904641519500

3,10 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307700

904641307300

3,10 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307300

904641519500

3,10 €

Unit Price Incl. Tax

BAND 5PK

1UA825910000 1UA825910000

2,60 €

Unit Price Incl. Tax

BAND 5PK

904643206000

12R825910000

2,60 €

Unit Price Incl. Tax

BATTERY (YTZ7S)

5TJ821000100 5TJ821000100

Not available

BRACKET BATTERY

2GB821280000 2GB821280000

77,33 €

Unit Price Incl. Tax

BOLT, WITH WASHER

901190613300 901190613300

1,40 €

Unit Price Incl. Tax

DAMPER

2GB821760000 2GB821760000

3,79 €

Unit Price Incl. Tax

BAND, BATTERY

8CY821310000 8CY821310000

13,75 €

Unit Price Incl. Tax

WIRE PLUS LEAD

2GB821150000 2GB821150000

22,84 €

Unit Price Incl. Tax

WIRE MINUS LEAD

2GB821160000 2GB821160000

18,17 €

Unit Price Incl. Tax

BOLT, FLANGE

901050606400 901050606400

1,29 €

Unit Price Incl. Tax

NUT, FLANGE(7NB)

957020650000

957010650000

2,23 €

Unit Price Incl. Tax

STARTER RELAY ASSY (RC19-102B)

2GB819400000 2GB819400000

63,71 €

Unit Price Incl. Tax

FUSE (12V 15A)

36Y821510000 36Y821510000

4,78 €

Unit Price Incl. Tax

COVER, LEAD WIRE

5SL821191000 5SL821191000

6,16 €

Unit Price Incl. Tax

BOLT, FLANGE

950220600800 950220600800

1,03 €

Unit Price Incl. Tax

RELAY ASSY (1ST-00)

1ST819500000 1ST819500000

17,71 €

Unit Price Incl. Tax

HOLDER, RELAY

5JJ819520000 5JJ819520000

7,93 €

Unit Price Incl. Tax

SENSOR, LEAN ANGLE

5VU825760100

5VU825760200

170,92 €

Unit Price Incl. Tax

BRACKET

2GB855420000 2GB855420000

28,22 €

Unit Price Incl. Tax

BOLT

913120402000 913120402000

1,11 €

Unit Price Incl. Tax

DAMPER

2GB835130000 2GB835130000

12,46 €

Unit Price Incl. Tax

PLATE HOLDER

2GB8252H0000 2GB8252H0000

13,41 €

Unit Price Incl. Tax

SCREW, TRUSS TAP.

977025001400

977015001400

1,14 €

Unit Price Incl. Tax

RELAY ASSY

1TP819500000 1TP819500000

18,51 €

Unit Price Incl. Tax

HOLDER, RELAY

5EA819520000 5EA819520000

7,20 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 2 of your Yamaha YZ250FX of 2015. Let us know if you have any questions.
