ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA WR250R 2012

WIRE, MINUS LEAD

3D7821160000 3D7821160000

42,23 €

Unit Price Incl. Tax

BOLT, FLANGE

950220601400 950220601400

0,98 €

Unit Price Incl. Tax

RECTIFIER & REGULATOR ASSY

4XY819600000 4XY819600000

329,80 €

Unit Price Incl. Tax

BOLT, FLANGE

950220603000 950220603000

1,22 €

Unit Price Incl. Tax

NUT

901790602000 901790602000

11,48 €

Unit Price Incl. Tax

BATTERY (YTZ7S)

1S4821001000

Not available

BAND, BATTERY

3L8821310100

22F821310000

8,84 €

Unit Price Incl. Tax

HOOK, BATTERY BAND

3D7213650000 3D7213650000

5,68 €

Unit Price Incl. Tax

WIRE, PLUS LEAD

3D7821150000 3D7821150000

40,45 €

Unit Price Incl. Tax

MAIN SWITCH STEERING LOCK

32D825011000

Not available

KEY, BLANK (5SJ1)

32D825110900

908905602800

18,09 €

Unit Price Incl. Tax

BOLT

901090819500

901090819600

6,09 €

Unit Price Incl. Tax

WIRE HARNESS ASSY

32D825901000 32D825901000

732,47 €

Unit Price Incl. Tax

FUSE (7.5A-BL)

5JJ821510000 5JJ821510000

4,70 €

Unit Price Incl. Tax

FUSE (15A)

5JJ821511000

67F821515000

2,42 €

Unit Price Incl. Tax

FUSE (10A)

5JJ821513000

67F821514000

11,05 €

Unit Price Incl. Tax

CLAMP

904651009800 904651009800

1,40 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307300

904641519500

3,10 €

Unit Price Incl. Tax

CLAMP(4GY)

904642019100 904642019100

4,99 €

Unit Price Incl. Tax

BAND 5PK

904641606100

12R825910000

2,60 €

Unit Price Incl. Tax

CLAMP

904642500400 904642500400

2,90 €

Unit Price Incl. Tax

CLAMP

904649900600 904649900600

7,66 €

Unit Price Incl. Tax

CLAMP

904642025800 904642025800

5,85 €

Unit Price Incl. Tax

BAND 5PK

1UA825910000 1UA825910000

2,60 €

Unit Price Incl. Tax

STOP SWITCH ASSY

3D7825300000

3D7825300100

57,76 €

Unit Price Incl. Tax

CLAMP

904640500100 904640500100

15,36 €

Unit Price Incl. Tax

BAND 5PK

904641606100

12R825910000

2,60 €

Unit Price Incl. Tax

STARTER RELAY ASSY (RC19-076A)

3D7819400000 3D7819400000

122,73 €

Unit Price Incl. Tax

FUSE (12V 30A)

1AE821510000 1AE821510000

2,79 €

Unit Price Incl. Tax

BOLT, FLANGE

950220600800 950220600800

1,03 €

Unit Price Incl. Tax

RELAY ASSY (5VK-40)

5VK819504000

Not available

RELAY ASSY (5JJ-20)

5JJ819502000 5JJ819502000

104,89 €

Unit Price Incl. Tax

HOLDER, RELAY

5JJ819520000 5JJ819520000

7,93 €

Unit Price Incl. Tax

SWICH SIDE STAND

5KN825664000

Not available

SCREW, PAN HEAD(3YL) 5PK

901570502500

985800501400

2,23 €

Unit Price Incl. Tax

CLAMP(4GY)

904640518800 904640518800

2,68 €

Unit Price Incl. Tax

BAND 5PK

904641606100

12R825910000

2,60 €

Unit Price Incl. Tax

CLAMP(4HM)

904641519200 904641519200

3,32 €

Unit Price Incl. Tax

BAND 5PK

904641606100

12R825910000

2,60 €

Unit Price Incl. Tax

CLAMP

904641600100 904641600100

2,68 €

Unit Price Incl. Tax

CLAMP

904641600300 904641600300

2,00 €

Unit Price Incl. Tax

HOSE

904462700100 904462700100

4,82 €

Unit Price Incl. Tax

CLAMP

904641600300 904641600300

2,00 €

Unit Price Incl. Tax

CLAMP(4GY)

904641019000 904641019000

3,75 €

Unit Price Incl. Tax

CLAMP

904641600300 904641600300

2,00 €

Unit Price Incl. Tax

FLASHER RELAY ASSY

4GY833500000

4GY833500100

115,56 €

Unit Price Incl. Tax

HORN

5XT833710000 5XT833710000

61,16 €

Unit Price Incl. Tax

BOLT, FLANGE

901050604800

958170601200

0,80 €

Unit Price Incl. Tax

CLAMP

904641600300 904641600300

2,00 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
