EXHAUST

CRANKCASE FOR YAMAHA YZ250F 2011

COVER - ENGINE 1

Item numbers

CRANKCASE ASSY

5XC1510030YX

5XC1510038YX

1 035,71 €

Unit Price Incl. Tax

PIN, DOWEL(4XL)

936121625400 936121625400

7,07 €

Unit Price Incl. Tax

NOT AVAILABLE

913120604500

Not available

BOLT, HEXAGON SOCKET HEAD(M01)

913120605500

9131N0605500

2,84 €

Unit Price Incl. Tax

BOLT

913120607000 913120607000

2,52 €

Unit Price Incl. Tax

BOLT, FLANGE

950221001600 950221001600

2,52 €

Unit Price Incl. Tax

GASKET (5R6) 5PK

904301018800

904301002700

4,78 €

Unit Price Incl. Tax

HOLDER, CLUTCH CABLE

5NL154410100 5NL154410100

19,98 €

Unit Price Incl. Tax

COVER, CRANKCASE 2

17D154215000 17D154215000

59,05 €

Unit Price Incl. Tax

BOLT, FLANGE

901050618900 901050618900

1,62 €

Unit Price Incl. Tax

GUIDE, CHAIN

5NL174660000 5NL174660000

31,99 €

Unit Price Incl. Tax

PLATE, BEARING COVER

5BE153830100 5BE153830100

10,38 €

Unit Price Incl. Tax

SCREW, COUNTERSUNK

901510604400 901510604400

1,40 €

Unit Price Incl. Tax

PLATE, BEARING COVER

5NL153880000 5NL153880000

8,02 €

Unit Price Incl. Tax

BOLT, FLANGE

901050608100

950220601200

1,03 €

Unit Price Incl. Tax

PLATE, BEARING COVER

4JT153810100 4JT153810100

15,24 €

Unit Price Incl. Tax

SCREW, COUNTERSUNK

901490607400

901510605200

1,62 €

Unit Price Incl. Tax

PLATE, STOPPER 2

5DH185620000 5DH185620000

7,20 €

Unit Price Incl. Tax

BOLT, FLANGE

901050608100

950220601200

1,03 €

Unit Price Incl. Tax

O-RING (371)

932101019700 932101019700

2,83 €

Unit Price Incl. Tax

PIN, DOWEL(3VD)

995301011400 995301011400

2,12 €

Unit Price Incl. Tax

COLLAR

903871800700 903871800700

32,95 €

Unit Price Incl. Tax

PIN, DOWEL(2VG)

995301011600 995301011600

1,93 €

Unit Price Incl. Tax

CLAMP

904651001300 904651001300

19,94 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CRANKCASE of your Yamaha YZ250F of 2011. Let us know if you have any questions.
