CAMSHAFT / TIMING CHAIN

OIL PUMP FOR YAMAHA TT-R 230 2025

INTAKE

Item numbers

OIL PUMP ASSY

5H0133000200 5H0133000200

198,50 €

Unit Price Incl. Tax

GEAR, PUMP DRIVEN 2

5H0133260100 5H0133260100

58,25 €

Unit Price Incl. Tax

PIN, DOWEL (137)

936031203000 936031203000

2,83 €

Unit Price Incl. Tax

GASKET, PUMP COVER

4BE133290100

3GD133290000

2,98 €

Unit Price Incl. Tax

NOT AVAILABLE

9870M0603000

Not available

COVER, PUMP GEAR

5H0133270000 5H0133270000

29,00 €

Unit Price Incl. Tax

STRAINER, OIL

51Y134110000

5YPE34110000

18,84 €

Unit Price Incl. Tax

SPRING, COMPRESSION (3Y1)

905011857600 905011857600

2,23 €

Unit Price Incl. Tax

PLUG, DRAIN

4VWE53510000

5H0153510000

16,72 €

Unit Price Incl. Tax

O-RING

93210347A100 93210347A100

2,00 €

Unit Price Incl. Tax

OIL CLEANER ASSY

5H0134400000

5H0134400900

16,96 €

Unit Price Incl. Tax

COUVERCLE, ELEMENT A HUILE

4VWE34470100 4VWE34470100

Not available

O-RING (341)

932105417500 932105417500

7,90 €

Unit Price Incl. Tax

BOLT (583 OIL DRAIN)

90109065G000

901090641900

3,67 €

Unit Price Incl. Tax

O-RING (583 OIL DRAIN 5PK

932100713500 932100713500

2,90 €

Unit Price Incl. Tax

BOLT, WASHER BASED(4KG)

9502M0602500

950270602500

2,23 €

Unit Price Incl. Tax

NOT AVAILABLE

90105064A600

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
